SCHNEIDER ELECTRIC LC2D09U7V Contactor IEC 240VAC 3P 9A
Item: AG6PNTModel: LC2D09U7VCross Ref: 3DY62
7 In Stock
Ships within 2 days via
10.00% off
€454.97 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Contactor |
| Action Type | Reversing |
| Auxiliary Contacts Included | 1NO/1NC |
| Coil Volts | 240V AC |
| Contactor Style | IEC |
| Contactor Type | IEC |
| Electrical Operating Durability | 2000000, 600000 |
| Enclosure Type | Open |
| Frequency | 50/60 Hz |
| Full Load Amps-inductive | 9A |
| Full Load Amps-resistive | 20A |
| Full Load Current - Resistive | 20A |
| Height | 3.54" |
| Horsepower @ Single Phase - 240v Ac | 1 hp |
| Horsepower @ Three Phase - 208v Ac | 2 hp |
| Horsepower @ Three Phase - 480v Ac | 5 hp |
| Hp @ 1 Phase - 120v | 1/2 hp |
| Hp @ 1 Phase - 230v | 1 hp |
| Hp @ 3 Phase - 208v | 2 hp |
| Hp @ 3 Phase - 230v | 2 hp |
| Hp @ 3 Phase - 240v | 2 hp |
| Hp @ 3 Phase - 575v | 7 1/2 hp |
| Hp @ Three Phase - 600v Ac | 7 1/2 hp |
| Includes | Electrical Interlock, Mechanical Interlock |
| Includes Auxiliary Contacts | Yes |
| Integrated Surge Suppression | No |
| Ip Rating | IP20 |
| Main Power Pole Contact Form | 3NO |
| Maximum Operating Temperature | 140°F |
| Maximum Voltage Rating | 690V AC |
| Mechanical Operating Durability | 15000000 |
| Minimum Operating Temperature | -40°F |
| Nema Enclosure Rating | No Enclosure |
| Nominal Coil Voltage @ 60hz | 240V AC |
| Number Of Poles | 3 |
| Overall Depth | 3.39" |
| Overall Height | 3.03" |
| Overall Width | 3.54" |
| Reversing Capability | Reversing |
| Series | Tesys Deca |
| Width | 3.54" |
| Wire Termination Type | Screw Clamp |
Shipping Info:
| Ship weight (kg) | 0.83 |
| Ship height (cm) | 7.7 |
| Ship length (cm) | 8.61 |
| Ship width (cm) | 8.99 |
| HS code | 8536490065 |
| Country of Origin | FR |
Product Variants
| Product | Model | Nominal Coil Voltage @ 60hz | Integrated Surge Suppression | Height | Coil Volts | Mechanical Operating Durability | Depth | Reversing Capability | Number Of Poles | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
LC2D09B7 | 24V AC | No | 3 4/5" | 24V AC | 15000000 | 5.3" | Reversing | 3 | €531.29 | |
|
LC2D09BD | 24V DC | Yes | 3.54" | 24V DC | 30000000 | 3.54" | Reversing | 3 | €505.52 | |
 |
LC2D09G7V | 120V AC | No | 3.54" | 120V AC | 15000000 | 3.54" | Reversing | 3 | €505.52 |
