SCHNEIDER ELECTRIC GV2ME03 Manual Motor Starter Button 0.25-0.4A 1P
Item: AH9JVDModel: GV2ME03Cross Ref: 3CY82
7 In Stock
Ships within 2 days via
5.00% off
€134.91 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Manual Motor Starter |
| Amps | 0.4A |
| Color | Gray |
| Depth | 2 3/5" |
| Electrical Operating Durability | 100000 |
| Enclosure Nema Rating | No Enclosure |
| Features | Phase Loss Sensitivity |
| Frequency | 50/60 Hz |
| Height | 3 1/2" |
| Included Pilot Light | No |
| Ip Rating | IP20 |
| Line Rated Amps | 0.4A |
| Max. Amps (ac) | 0.4A |
| Max. Operating Temp. | 140°F |
| Max. Overload Relay Amps Setting | 0.4A |
| Max. Voltage | 600V AC , 690V AC |
| Mechanical Operating Durability | 100000 |
| Min. Operating Temp. | -4°F |
| Min. Overload Relay Amps Setting | 0.25A |
| Nema Size | Not Applicable |
| No. Of Poles | 3 |
| Operator | Push Button |
| Overall Depth | 3.09" |
| Overall Height | 3 1/2" |
| Overall Width | 1.77" |
| Overload Protection Type | Thermal |
| Overload Relay Amps Setting | 0.25-0.4A |
| Phase | 3 |
| Phase Loss Sensitivity | Yes |
| Pilot Light | Yes |
| Power Dissipation Per Pole | 2.5 W |
| Product Datasheet | schneider-electric-gv2me03.pdf |
| Resistance Properties | Fire Resistant |
| Reversing Capability | Non Reversing |
| Series | Tesys Deca |
| Starter Style | IEC |
| Status Indicator | LED Indicator |
| Terminal Connection Type | Screw Clamp Terminals |
| Thermal Units Required | None (Starter Includes Integrated Thermal Units) |
| Trip Class | Class 10 |
| Width | 1 3/4" |
| Wire Termination Type | Screw Clamps |
Shipping Info:
| Ship weight (kg) | 0.25 |
| Ship height (cm) | 8.89 |
| Ship length (cm) | 7.85 |
| Ship width (cm) | 4.5 |
| Country of Origin | FR |
Product Details:
- Enclosure NEMA Rating : No Enclosure
- Phase Loss Sensitivity : No
- Special Features: Single Unit, Melting Alloy Thermal Overload
Documentation:
Product Variants
| Model | Height | Amps | Max. Voltage | Depth | Overload Relay Amps Setting | Pilot Light | Operator | Overall Width | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| GV2ME01 | 3 1/2" | 48-65A | 600V AC | 3.03" | 0.1-0.16A | Yes | Push Button | 1.77" | €126.17 | |
| GV2ME02 | 3 1/2" | 60-100A | 600V AC | 3.03" | 0.16-0.25A | No | Push Button | 1.77" | €133.72 | |
| GV2ME32 | 3 1/2" | 24-32A | 600V AC | 3.03" | 24-32A | No | Push Button | - | €191.95 | |
| GV2P01 | 3 1/2" | - | 600V AC | 3.83" | 0.1-0.16A | No | Selector Switch | 1.77" | €205.72 | |
| GV2P02 | 3 1/2" | - | 600V AC | 3.83" | 0.16-0.25A | No | Selector Switch | 1.77" | €205.72 | |
| GV2P03 | 3 1/2" | 15-25A | 600V AC | 3.83" | 0.25-0.4A | No | Selector Switch | 1.77" | €205.72 | |
| GV2P04 | 3 1/2" | - | 600V AC | 3.83" | 0.4-0.63A | Yes | Selector Switch | 1.77" | €328.04 |
