SCHNEIDER ELECTRIC CAD50G7 IEC Control Relay 5NO 120VAC 10A
Item: AH9JWHModel: CAD50G7Cross Ref: 3EA21
7 In Stock
Ships within 2 days via
5.00% off
€123.53 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | IEC Control Relay |
| Amps | 10A |
| Body Depth | 3.31" |
| Body Depth-relay | 3.15" |
| Body Height | 2.91" , 3.03" |
| Body Width | 1.77" |
| Body Width-relay | 1.77" |
| Coil Voltage | 120V AC |
| Compatible With Series | Tesys D Control Relays |
| Contact Material | Silver Nickel |
| Contactor Application | Control Circuit |
| Depth | 84 mm |
| Electrical Connection | Screw Clamp |
| Frequency | 50/60 Hz |
| Height | 77 mm |
| Min. Switching Amps | 5 mA |
| Min. Switching Voltage | 17V |
| Mounting | DIN Rail, Panel |
| No. Of Pins | 12 |
| No. Of Pins-relay | 12 |
| Overall Height | 3.03" |
| Overall Height-relay | 3.03" |
| Power Consumption | 8 VA |
| Power Consumption-relay | 8 VA |
| Product Datasheet | schneider-electric-cad50g7.pdf |
| Resistive Contact Amp Rating | 10A |
Shipping Info:
| Ship weight (kg) | 0.36 |
| Ship height (cm) | 7.7 |
| Ship length (cm) | 8.41 |
| Ship width (cm) | 4.5 |
| Country of Origin | ID |
Documentation:
Product Variants
| Model | Coil Voltage | Frequency | Height | Overall Height | Body Width | Body Depth | Body Height | Body Width-relay | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| CA2KN22B7 | 24V AC | 50/60 Hz | 58 mm | 2 7/25" | 1.77" | 2 6/25" | 2 7/25" | 1.77" | €71.17 | |
| CA2KN22G7 | 120V AC | 50/60 Hz | 58 mm | 2 7/25" | 1.77" | 2 6/25" | 2 7/25" | 1.77" | €65.97 | |
| CA2KN22T7 | 480V AC | 50/60 Hz | 58 mm | 2 7/25" | 1.77" | 2 6/25" | 2 7/25" | 1.77" | €65.97 | |
| CA2KN22U7 | 240V AC | 50/60 Hz | 58 mm | 2 7/25" | 1.77" | 2 6/25" | 2 7/25" | 1.77" | €68.37 | |
| CA2KN31B7 | 24V AC | 50/60 Hz | 58 mm | 2 7/25" | 1.77" | 2 6/25" | 2 7/25" | 1.77" | €68.61 | |
| CA2KN31G7 | 120V AC | 50/60 Hz | 58 mm | 2 7/25" | 1.77" | 2 6/25" | 2 7/25" | 1.77" | €68.61 | |
| CA2KN31U7 | 240V AC | 50/60 Hz | 58 mm | 2 7/25" | 1.77" | 2 6/25" | 2 7/25" | 1.77" | €68.61 |
