SCHNEIDER ELECTRIC CAD50BD IEC Control Relay 5NO 24VDC 10A
Item: AH9JWKModel: CAD50BDCross Ref: 3EA29
7 In Stock
Ships within 2 days via
10.00% off
€257.28 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | IEC Control Relay |
| Body Depth | 3.66" |
| Body Depth - Relay | 4 18/25" |
| Body Height | 3.03" |
| Body Width | 1.77" |
| Body Width - Relay | 1.77" |
| Coil Volts | 24V DC |
| Compatible With Series | Tesys D Control Relays |
| Contact Form | 5No |
| Contact Material | Silver Nickel |
| Contact Rating (ac) | 10A @ 120/240/480/600V |
| Contactor Application | Control Circuit |
| Current Rating | 10A |
| Dc Contact Rating | 2A @ 125/250/600V |
| Depth | 93 mm |
| Electrical Connection | Screw Clamp |
| Electrical Connection Type | Screw |
| Features | Finger Safe |
| Frequency | Not Applicable |
| Height | 77 mm |
| Input Voltage | 24V DC |
| Ip Rating | IP2X |
| Maximum Operating Temperature | 140°F |
| Min. Switching Amps | 5 mA |
| Min. Switching Voltage | 17V |
| Minimum Operating Temperature | -40°F |
| Mounting | Din Rail, Panel |
| Number Of Pins | 12 |
| Number Of Pins - Relay | 12 |
| Number Of Terminals | 12 |
| Overall Height | 3.03" |
| Overall Height - Relay | 3.03" |
| Power Consumption | 5.4 W |
| Power Consumption - Relay | 8 VA |
| Relay Frame Size | Standard |
| Relay Mounting Style | Din-Rail, Surface |
| Relay Style | IEC |
| Resistive Contact Amp Rating | 10A |
| Response Time | 16 ms to 24 ms (Coil De-Energisation And No Opening), 53 ms to 72 ms (Coil Energisation And No Closing) |
| Series | Tesys D Control Relays |
| Time Constant | 28 ms |
Shipping Info:
| Ship weight (kg) | 0.52 |
| Ship height (cm) | 7.7 |
| Ship length (cm) | 9.3 |
| Ship width (cm) | 4.5 |
| Country of Origin | ID |
Product Variants
| Model | Coil Volts | Height | Depth | Mounting | Resistive Contact Amp Rating | Contact Material | Ip Rating | Price | |
|---|---|---|---|---|---|---|---|---|---|
| CA2KN22B7 | 24V AC | 58 mm | 57 mm | Din Rail, Panel | 10A | Silver Nickel | IP2X | €95.40 | |
| CA2KN22G7 | 120V AC | 58 mm | 57 mm | Din Rail, Panel | 10A | Silver Nickel | IP2X | €95.40 | |
| CA2KN22T7 | 480V AC | 58 mm | 57 mm | Din Rail, Panel | 10A | Silver Nickel | IP2X | €95.40 | |
| CA2KN22U7 | 240V AC | 58 mm | 57 mm | Din Rail, Panel | 10A | Silver Nickel | IP2X | €95.40 | |
| CA2KN31B7 | 24V AC | 58 mm | 57 mm | Din Rail, Panel | 10A | Silver Nickel | IP2X | €101.19 | |
| CA2KN31G7 | 120V AC | 58 mm | 57 mm | Din Rail, Panel | 10A | Silver Nickel | IP2X | €101.19 | |
| CA2KN31U7 | 240V AC | 58 mm | 57 mm | Din Rail, Panel | 10A | Silver Nickel | IP2X | €101.19 |
