SCHNEIDER ELECTRIC 8501CDO22V51 Open Power Relay, Surface Mounted, 20 A Current Rating, 12V DC, 8 Pins/Terminals, DPDT
Get it by Friday, Aug 28
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Open Power Relay |
| Amps | 20A |
| Base Shape | Square |
| Body Depth | 1.39" , 2.53" |
| Body Height | 3 3/25" , 3.13" |
| Body Width | 2 1/2" |
| Coil Voltage | 12V DC |
| Contact Form | DPDT |
| Dc Contact Rating | 10A @ 120V |
| Electrical Connection | Screw |
| Electrical Connection Type | Screw |
| Electrical Connection-power Relay | Screw Clamp |
| Environmental Protection | Open |
| Features | Durable Open-Frame Construction, Green Premium Product |
| Flat Pin Width | Not Applicable |
| Mfr. Series | 8501C Series |
| No. Of Pins | 8 |
| No. Of Pins/terminals | 8 |
| Overall Depth | 2.31" |
| Overall Height | 3 3/25" |
| Power Consumption | 2 W |
| Power Consumption-relay | 2 W |
| Product Datasheet | schneider-electric-8501cdo22v51.pdf |
| Push-to-test Button | No Test Button |
| Relay Mounting | Through Panel |
| Relay Mounting Style | Surface |
| Sealing | Open |
| Status Indicator | No |
Shipping Info:
| Ship weight (kg) | 0.22 |
| Ship height (cm) | 7.95 |
| Ship length (cm) | 3.53 |
| Ship width (cm) | 6.35 |
| Country of Origin | CN |
Documentation:
Product Variants
| Model | Relay Mounting Style | Coil Voltage | Type | Frequency | Contact Form | Push-to-test Button | No. Of Pins/terminals | Electrical Connection Type | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| RPF2AB7 | DIN Rail, Surface | 24V AC | - | 50/60 Hz | DPST, NO | No Test Button | 6 | Tab | €23.38 | |
| RPF2AF7 | - | 120V AC | - | 50/60 Hz | - | - | - | - | €23.38 | |
| RPF2AP7 | DIN Rail, Surface | 230V AC | - | 50/60 Hz | DPST, NO | No Test Button | 6 | Tab | €23.38 | |
| RPF2BJD | DIN Rail, Surface | 12V DC | - | 50/60 Hz | DPDT | No Test Button | 8 | Tab | €23.05 | |
| RPF2BBD | DIN Rail, Surface | 24V DC | - | 50/60 Hz | DPDT | No Test Button | 8 | Tab | €23.05 | |
| RPF2BB7 | DIN Rail, Surface | 24V AC | - | 50/60 Hz | DPDT | No Test Button | 8 | Tab | €23.05 | |
| RPF2BF7 | DIN Rail, Surface | 120V AC | - | 50/60 Hz | DPDT | No Test Button | 8 | Tab | €23.05 |
