SCHNEIDER ELECTRIC 788XCXRC-12D Plug-In Relay 11 Pins Square 12VDC
Item: AH4TNMModel: 788XCXRC-12DCross Ref: 35KR66
7 In Stock
Ships within 2 days via
13.00% off
€26.33 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Plug-In Relay |
| Ac Contact Rating | 10A @ 277V |
| Amps | 10A |
| Base Type | Square |
| Coil Voltage | 12V DC |
| Contact Form | 3PDT |
| Contact Material | Silver Alloy |
| Contact Rating (ac) | 5A @ 250V-1 (NC), 10A @ 277V |
| Dc Contact Rating | 10A @ 28V |
| Dielectric Strength | 1500V AC Between Contacts, 2000V AC Between Poles, 2500V AC Between Coil And Contact |
| Electrical Connection Type | Tab |
| Electrical Operating Durability | 100000 |
| Hp @ 120v | 1/3 hp |
| Hp @ 240v | 1/2 hp |
| Mechanical Operating Durability | 5000000 |
| Motor Rated | Yes |
| No. Of Pins | 11 |
| No. Of Pins/terminals | 11 |
| No. Of Poles | 3 |
| Product Datasheet | schneider-electric-788xcxrc-12d.pdf |
| Push-to-test Button | Manual Push Test Button |
| Relay Mounting Style | Socket |
| Sealing | Enclosed |
| Series | 788R Series |
| Socket Code | C |
| Status Indicator | Mechanical Flag |
| Type | General Purpose |
Shipping Info:
| Ship weight (kg) | 0.08 |
| Ship height (cm) | 3.56 |
| Ship length (cm) | 5 |
| Ship width (cm) | 3.51 |
| Country of Origin | CN |
Documentation:
Product Variants
| Model | Relay Mounting Style | Coil Voltage | Type | Frequency | Contact Form | Push-to-test Button | No. Of Pins/terminals | Electrical Connection Type | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| RPF2AB7 | DIN Rail, Surface | 24V AC | - | 50/60 Hz | DPST, NO | No Test Button | 6 | Tab | €23.38 | |
| RPF2AF7 | - | 120V AC | - | 50/60 Hz | - | - | - | - | €23.38 | |
| RPF2AP7 | DIN Rail, Surface | 230V AC | - | 50/60 Hz | DPST, NO | No Test Button | 6 | Tab | €23.38 | |
| RPF2BJD | DIN Rail, Surface | 12V DC | - | 50/60 Hz | DPDT | No Test Button | 8 | Tab | €23.05 | |
| RPF2BBD | DIN Rail, Surface | 24V DC | - | 50/60 Hz | DPDT | No Test Button | 8 | Tab | €23.05 | |
| RPF2BB7 | DIN Rail, Surface | 24V AC | - | 50/60 Hz | DPDT | No Test Button | 8 | Tab | €23.05 | |
| RPF2BF7 | DIN Rail, Surface | 120V AC | - | 50/60 Hz | DPDT | No Test Button | 8 | Tab | €23.05 |
