SCHNEIDER ELECTRIC 784XDXC-12D 12VDC, 14-Pin Square Base General Purpose General Purpose Relay
Item: CD2KLUModel: 784XDXC-12DCross Ref: 6CWJ0
7 In Stock
Ships within 2 days via
13.00% off
€24.58 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | General Purpose Relay |
| Ac Contact Rating | 15A @ 120V, 12A @ 277V |
| Amps | 15A |
| Base Type | Square |
| Body Height | 1 2/5" |
| Body Width | 1 3/5" |
| Coil Voltage | 12V DC |
| Contact Form | 4PDT |
| Contact Material | Silver Alloy |
| Contact Rating (ac) | 7.55A @ 250V, 10A @ 151/277V, 15A @ 120 to 277/120/150/250V |
| Contact Rating (dc) | 7.55A @ 28V (Nc), 15A @ 28V (No) |
| Dc Contact Rating | 12A @ 28V |
| Depth | 1.1" |
| Dielectric Strength | 1500V AC Between Contacts, 2000V AC Between Coil And Contact, 2000V AC Between Poles |
| Electrical Connection Type | Tab |
| Electrical Operating Durability | 100000 |
| Hp @ 120v | 1/2 hp |
| Hp @ 240v | 3/4 hp |
| Mechanical Operating Durability | 10000000 |
| Motor Rated | Yes |
| Mounting | Plug In |
| No. Of Pins | 14 |
| No. Of Pins/terminals | 14 |
| Overall Height | 1 16/25" |
| Product Datasheet | schneider-electric-784xdxc-12d.pdf |
| Push-to-test Button | No Test Button |
| Relay Mounting Style | Socket |
| Series | 784 Series |
| Socket Code | F |
| Status Indicator | Mechanical Flag |
