REELCRAFT 81100OHP Hose Reel, Inner Diameter 3/8 Inch, 4800 Psi, Hose Length 100 Feet
Get it by Wednesday, Dec 24
10.00% off
€1,882.05 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Hose Reel |
| Base Motion Type | Stationary |
| Bearing Construction | Ball |
| Bearing Type | Permanent Lubricated |
| Corrosion-resistant | Yes |
| Drive Type | Spring Return |
| Duty Rating | General, Industrial |
| Enclosed | No |
| Fasteners Included | No |
| Features | Long Life And Trouble Free Performance |
| Finish | Powder Coated |
| Fitting Size | 3/8" x 3/8" |
| Fitting Type | NPT x NPT |
| For Dual Hose | No |
| Height | 25 3/8" |
| Hose Capacity | 100 ft. |
| Hose Color | Black |
| Hose Cover Material | Synthetic Rubber |
| Hose End Configuration | 3/8" MNPT |
| Hose Fitting A Gender | Male |
| Hose Fitting A Material | Steel |
| Hose Fitting A Size | 3/8" |
| Hose Fitting A Type | NPT |
| Hose Fitting B Gender | Male |
| Hose Fitting B Material | Steel |
| Hose Fitting B Size | 3/8" |
| Hose Fitting B Type | NPT |
| Hose Inside Dia. | 3/8" |
| Hose Length | 100 ft. |
| Hose Outlet (in.) | 3/8" (M)NPT |
| Hose Outlet Type | MNPT |
| Hose Outside Dia. | 3/4" |
| Hose Reel Primary Application | Grease |
| Hose Reel Type | Ceiling, Floor, Vehicle, Wall Mount Hose Reel |
| Hose Tube Material | Synthetic Rubber |
| Housing Material | Steel |
| Includes | Hose, Bumper |
| Includes Hose | Yes |
| Includes Hose Stop | Yes |
| Includes Leader Hose | No |
| Latch Type | Spring Loaded |
| Length | 24" |
| Max. Pressure | 4800 psi |
| Max. Temp. | 210°F |
| Maximum Operating Pressure | 4800 psi |
| Minimum Operating Temperature | 32°F |
| Mount Base Height | 12" |
| Mount Base Width | 7 11/32" |
| Mount Hole Diameter | 1/2" |
| Mounting | Ceiling, Floor, Wall |
| Mounting Hole Center To Center Height | 10" |
| Mounting Hole Center To Center Width | 6" |
| Number Of Guide Arms | 2 |
| Number Of Mount Holes | 4 |
| Overall Height | 25 3/8" |
| Overall Length | 24" |
| Overall Width | 10 1/2" |
| Pedestal Type | Dual Pedestal |
| Product Datasheet | reelcraft-81100ohp.pdf |
| Reel Color | Red |
| Reel Diameter | 15 1/2" |
| Reel Finish | Powder Coated |
| Reel Material | Carbon Steel |
| Reel Width | 10 1/2" |
| Seal Material | Neoprene |
| Speed Limited Retraction | No |
| Spiral Hose Guard | No |
| Swivel Finish | Nickel Plated , Steel |
| Swivel Inlet Gender | Female |
| Swivel Inlet Size | 3/8" |
| Swivel Inlet Thread Size | 3/8"-18 |
| Swivel Inlet Type | NPT |
| Swivel Material | Zinc Plated Steel |
| Swivel Outlet Gender | Male |
| Swivel Outlet Size | 1/2" |
| Swivel Outlet Thread Size | 1/2"-14 |
| Swivel Outlet Type | NPT |
| Twin Hose Compatible | No |
| Weight | 127 lbs. |
| Width | 10 1/2" |
Shipping Info:
| Ship weight (kg) | 53.55 |
| Ship height (cm) | 72.64 |
| Ship length (cm) | 72.14 |
| Ship width (cm) | 26.42 |
| HS code | 3917390050 |
| Country of Origin | US |
Documentation:
Product Variants
| Product | Model | Swivel Material | Hose Capacity | Reel Color | Reel Material | Number Of Guide Arms | Hose Included | Fitting Size | Max. Temp. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
81100OLP | - | - | - | - | - | - | - | 150°F | €1,362.80 | |
|
82075OLP | Nickel Plated Steel | 75 ft. | Red | Carbon Steel | 1 | - | 1/2" x 1/2" | 150°F | €1,294.74 | |
|
D84050OLP | Nickel Plated Steel | 50 ft. | Red | Carbon Steel | 2 | - | 3/4" x 3/4" | 150°F | €1,601.62 | |
|
82075OMP | Nickel Plated Steel | 75 ft. | Red | Carbon Steel | 1 | - | 1/2" x 1/2" | 210°F | €1,598.14 | |
|
83050OMP | Nickel Plated Steel | 50 ft. | Red | Carbon Steel | 2 | - | 3/4" x 3/4" | 210°F | €1,665.00 | |
 |
PW81000OHP | Nickel Plated Steel | 100 ft. | Red | Steel | 2 | - | - | 400°F | €1,496.35 | |
 |
82000OLS | Stainless Steel | 100 ft. | Silver | Stainless Steel | 2 | - | - | 210°F | €3,673.40 |
