PRO1 IAQ T601-2 Low Voltage Thermostat, Electric Forced Air Furnaces/Gas Forced Air Furnaces/Millivolt

Item: CT7ZYNModel: T601-2Cross Ref: 45KE98

7 In Stock

Ships within 2 days via

~~€88.38~~

10.00% off

€79.54 /unit

Add To Cart

Request a Quote

Payment

Product Specifications:

Item	Low Voltage Thermostat
750mv Compatible	Yes
Amps	1.5A
Application	Heat Or Cool
Automatic Changeover	No
Backlit Screen Color	Blue
Batteries Included	Yes
Battery Backup	Yes
Battery Type	(2) AA Batteries
Changeover Type	Manual
Color	White
Control Type	Push Button
Dehumidification Control	No
Depth	1 7/64"
Differential Temp.	+0.2°F to +2°F
Differential Type	Adjustable
Digit Size	Easy Read
Display Type	Digital
Dual Transformer Compatible	No
Electrical Connection Type	Hardwired
Fan Settings	Auto On
Features	Single Stage 1H/1C
Filter Change Reminder	No
Filter Indicator	No
Frequency	50/60 Hz
Housing Color	White
Humidification Control	No
Includes Positive Off	Yes
Key Pad Lockout	No
Low-battery Indicator	Yes
Max. Control Temp.	90°F
Max. Operating Temp.	105°F
Maximum Operating Humidity	90%
Millivolt Compatible	Yes
Min. Control Temp.	44°F
Min. Operating Temp.	32°F
Mounting Direction	Horizontal, Vertical
Mounting Location	Junction Box, Wall
Mounting Type	Sub Base Mount
Number Of Cooling Stages - Conventional System	1
Number Of Heating Stages - Conventional System	1
Output Signal	Not Applicable
Overall Depth	1 1/16"
Overall Height	4 3/8"
Overall Width	4 11/16"
Programmable Fan	No
Remote Sensing Capability	No
Shape	Square
Stages	1 H/1 C Conventional
Stages Cool	1
Stages Heating/cooling	1 H/1 C Conventional
Temp. Differential	0.2°F to 2°F
Temp. Sensitivity	-1°F to +1°F
Temperature Limiting	No
Temperature Scale	Celsius, Fahrenheit
Temporary Program Override	No
Temporary Temperature Hold	No
Terminal Designations	B, G, O, Rc, Rh, W, Y
Thermostat Type	Low Voltage
Type	Low Voltage
Voltage	18V AC

Shipping Info:

Ship weight (kg)	0.3
Ship height (cm)	11.11
Ship length (cm)	2.7
Ship width (cm)	11.91
Country of Origin	MX

Product Variants

Model	Display Type	Application	Terminal Designations	Voltage	Mounting Direction	Differential Temp.	Mounting Location	Max. Control Temp.	Price
T731W	Digital	Heat And Cool	B, C, Gh, Gl, O, R, W, Y	18V AC	Horizontal, Vertical	+0.2°F to +2°F	Junction Box, Wall	90°F	€330.14
T721	Digital	Heat Or Cool	B, C, G, O, R, W/E, W2, Y	18V AC	Horizontal, Vertical	+0.2°F to +2°F	Junction Box, Wall	90°F	€127.11
T621-2	Digital	Heat Or Cool	B, C, E, G, O, R, W2, Y	18/30V AC	Horizontal, Vertical	+0.2°F to +2°F	Junction Box, Wall	90°F	€117.98
T501M	Analog	Heat And Cool	B, G, O, Rc, Rh, W, Y	24V AC	Vertical	1°F	Wall	90°F	€73.32
T771	Digital	Heat Or Cool	C, G, Rc, Rh, Y/W	18V AC	Horizontal, Vertical	+0.2°F to +2°F	Junction Box, Wall	99°F	€93.09
T701	Digital	Heat Or Cool	B, C, G, O, Rc, Rh, W, Y	18/30V AC	Horizontal, Vertical	+0.2°F to +2°F	Junction Box, Wall	90°F	€95.60
T731WO	Digital	Heat And Cool	B, C, Gh, Gl, O, R, W, Y	18V AC	Horizontal, Vertical	+0.2°F to +2°F	Junction Box, Wall	90°F	€391.04
