PARKER 1.06DXPSRDB04.00 Pneumatic Cylinder
Get it by Tuesday, Aug 25
€110.51 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Cylinder |
| Ambient Air Temp. | 32°F to 160°F |
| Ambient Air Temp. For Operation | 32°F to 160°F |
| Application Type | General Industry Assembly Conveyors Packaging |
| Bore Size | 1 1/16" |
| Chemical Resistance | Corrosion Resistance |
| Connection Type | 2 X 1/8" NPT Threaded Pneumatic Ports 5/16"-24 UNF Male Threaded Rod-End |
| Design | "Lipseal" Piston Acetal Resin Head And Cap Piston Bumpers Both Ends Non-Repairable |
| Dia. | 5/16" |
| Function | Double-Acting Stainless Steel Pneumatic Cylinder |
| Main Function | Pneumatic Cylinder |
| Material | Stainless Steel Cylinder Body Aluminium Piston Oil-Impregnated Bronze Rod Bushing Stainless Steel Piston Rod |
| Max. Air Pressure | 100 psig |
| Max. Air Service Pressure | 100 psig |
| Mounting | Pivot, Nose Mounting |
| Mounting Mode | Pivot And Nose Mounting (Without Pivot Pin) |
| Rod Dia. | 5/16" |
| Shape | Cylindrical |
| Stroke Length | 4" |
Shipping Info:
| Ship weight (kg) | 1.13 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 2.54 |
Product Variants
| Product | Model | Stroke Length | Mounting | Max. Air Service Pressure | Rod Dia. | Max. Air Pressure | Dia. | Bore Size | Shape | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
1.06DSRD08.00 | 8" | Nose Mounting | 100 psig | 5/16" | 100 psig | 5/16" | 1 1/16" | Cylindrical | €110.88 | |
 |
1.06DXPSRDV26.25 | 26 1/4" | Pivot, Nose Mounting | 100 psig | 5/16" | 100 psig | 5/16" | 1 1/16" | Cylindrical | €220.54 | |
 |
1.06DSRD01.29 | 1.29" | Nose Mounting | 100 psig | 5/16" | 100 psig | 5/16" | 1 1/16" | Cylindrical | €87.26 | |
 |
1.06DSRD06.00 | 6" | Nose Mounting | 100 psig | 5/16" | 100 psig | 5/16" | 1 1/16" | Cylindrical | €97.81 | |
 |
1.06DSRDBW06.00 | 6" | Nose Mounting | 100 psig | 5/16" | 100 psig | 5/16" | 1 1/16" | Cylindrical | €112.97 | |
 |
1.06DSRDBW03.00 | - | - | - | - | - | - | - | - | €101.81 | |
|
1.06DSRDB00.60 | - | - | - | - | - | - | - | - | €87.65 |
