PARKER 07R413AC Compressed Air Regulator, 3/4 Inch NPT, 90 cfm, 2 psi to 125 psi, 250 psi Max Op Pressure
Item: BT6JRQModel: 07R413ACCross Ref: 409X59
7 In Stock
Ships within 2 days via
10.00% off
€245.89 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Adjustment Knob | Nonrising |
| Adjustment Location | Top |
| Adjustment Mechanism | Knob |
| Adjustment Mechanism Material | Steel |
| Adjustment Range - Regulators | 0 psi to 125 psi |
| Air Flow Direction | Left To Right |
| Air Inlet Gender | Female |
| Air Inlet Size | 3/4" |
| Air Outlet Gender | Female |
| Air Outlet Size | 3/4" |
| Air Outlet Type | NPT |
| Air Preparation Product Type | Regulator |
| Air Preparation Series | General Industrial Series |
| Body Material | Aluminum, Zinc |
| Flow Range | 75-99 SCFM |
| For Fluid Type | Air |
| For Substance Type | Air |
| Includes | (2) Gauge Plugs, Regulator |
| Maximum Flow Rate | 90 CFM |
| Maximum Operating Pressure | 250 psi |
| Maximum Operating Temperature | 175°F |
| Maximum Regulated Pressure | 125 psi |
| Minimum Operating Temperature | 32°F |
| Minimum Regulated Pressure | 2 psi |
| Modular Connection | Modular Connection |
| Number Of Air Inlets | 1 |
| Number Of Air Outlets | 1 |
| Operating Temp. Range | 0°C to 80°C |
| Overall Depth | 3 1/4" |
| Overall Height | 6" |
| Overall Length | 3 1/4" |
| Overall Width | 2 3/4" |
| Overall Width - Regulators | 2 21/25" |
| Pipe Size - Regulators | 3/4" |
| Port Inch/bsp | NPT |
| Port Size | 3/4" |
| Port Type | NPT |
| Pressure Gauge Included | No |
| Pressure Gauge Port Size | 1/4" |
| Pressure Gauge Port Type | NPT |
| Regulator Type | Relieving |
| Relieving/non-relieving | Relieving |
| Seal Material | Nitrile |
| Secondary Pressure Range | 2 psig to 125 psig |
| Series | 07R STANDARD Series |
| Supply Pressure Range | 0 psig to 250 psig |
| System Location | Air Line |
| Valve Design | Balanced |
| Weight | 2.5 lbs. |
Shipping Info:
| Ship weight (kg) | 1.13 |
| Ship height (cm) | 15.24 |
| Ship length (cm) | 8.26 |
| Ship width (cm) | 6.99 |
| Country of Origin | US |
Product Variants
| Product | Model | Air Inlet Size | Air Outlet Size | Body Material | Pressure Gauge Included | Overall Width | Adjustment Knob | Overall Length | Air Flow Direction | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
07R313AC | 1/2" | 1/2" | Aluminum, Zinc | No | 2 3/4" | Nonrising | 3 1/4" | Left To Right | €270.48 |
