OSG 1651001908 Spiral Point Tap Plug 14 x 2.00mm V Coating | AG2XXG 32NH44

OSG 1651001908 Spiral Point Tap Plug 14 x 2.00mm V Coating

Item: AG2XXGModel: 1651001908Cross Ref: 32NH44
7 In Stock

Ships within 2 days via

€168.69
10.00% off
€151.82 /unit
Add To Cart
Request a Quote

Payment

Product Specifications:

Item Spiral Point Tap
55% Thread Drill Size 12.5 mm
65% Thread Drill Size 31/64"
75% Thread Drill Size 12 mm
Class Of Fit Class 6H
Coolant Fed Non Coolant Through
Drill Bit Size 11.92 mm, 12.05 mm, 12.18 mm, 12.31 mm, 12.44 mm
Extended Neck Yes
Finish TiCN
List Number 16510
Measurement System Metric
Number Of Flutes 3
Overall Length 110 mm
Pitch Diameter Limits D7
Pitch Type 2 mm
Primary Material Application Hardened Steel, Stainless Steel, Steel
Primary Material Application Iso Code H, M, P
Secondary Material Application Aluminum, Brass, Bronze, Cast Iron, Copper, Steel
Secondary Material Application Iso Code K, N, P
Shank Dia. 10.89 mm
Shank Length 74 mm
Shank Type - Machining Straight
Size M14
Spiral Direction Neutral
Square Size 8.18 mm
Standards Ansi, Din
Tap Chamfer Modified Bottoming, Semi Bottoming
Tap Finish TiCN
Tap Length Standard DIN
Tap Material VC 10
Tap Shank Standard ANSI
Tap Thread Size M14 x 2
Tap Type Plug
Thread Direction Right Hand
Thread Length 24 mm
Thread Limit D7
Thread Limit / Class Of Fit D7, 6H
Thread Pitch 2 mm
Thread Size M14 x 2
Thread Standard Metric Coarse
Thread Type Metric Coarse

Shipping Info:

Ship weight (kg) 0.09
Ship height (cm)2.03
Ship length (cm)12.95
Ship width (cm)2.54
HS code8207400000

Product Variants

ProductModelThread SizeThread LengthOverall LengthThread LimitNumber Of Flutes75% Thread Drill SizeThread StandardThread TypePrice
OSG 1651002308 Spiral Point Tap Plug 18 x 2.50mm V Coating | AG2XNF 32NH48 1651002308M18 x 2.530 mm125 mmD735/8"Metric CoarseMetric Coarse€262.78
OSG 1651002408 Spiral Point Tap Plug 20 x 1.50mm V Coating | AG2XNG 32NH49 1651002408M20 x 1.530 mm125 mmD6418.75 mmMetric FineMetric Fine€365.83
OSG 1651002508 Spiral Point Tap Plug 20 x 2.50mm V Coating | AG2XNH 32NH50 1651002508M20 x 2.530 mm140 mmD730.7031"Metric CoarseMetric Coarse€365.80
OSG 1651002608 Spiral Point Tap Plug 22 x 1.50mm V Coating | AG2XNJ 32NH51 1651002608M22 x 1.530 mm125 mmD6420.75 mmMetric FineMetric Fine€399.44
OSG 1651000108 Spiral Point Tap Plug 3 x 0.50mm V Coating | AG2XWM 32NH26 1651000108M3 x 0.56 mm56 mmD332.5 mmMetric CoarseMetric Coarse€56.89
OSG 1651000208 Spiral Point Tap Plug 4 x 0.50mm V Coating | AG2XWN 32NH27 1651000208M4 x 0.58 mm63 mmD333.5 mmMetric FineMetric Fine€50.86
OSG 1651000308 Spiral Point Tap Plug 4 x 0.70mm V Coating | AG2XWP 32NH28 1651000308M4 x 0.78 mm63 mmD433.3 mmMetric CoarseMetric Coarse€46.69
