NTN SUCPPL207-20 Mounted Ball Bearing 1-1/4 Inch Bore
Item: AE7NCNModel: SUCPPL207-20Cross Ref: 5ZMX8
7 In Stock
Ships within 2 days via
€549.05 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Mounted Ball Bearing |
| Base Height | 0.708" |
| Bearing Insert Material | Stainless Steel |
| Bearing Insert Type | Radial Ball |
| Bearing Material Grade | 440C |
| Bolt Hole Size | 12 mm |
| Bore Dia. | 1 1/4" |
| Closure | Double Sealed |
| Color | White |
| Dynamic Load Capacity | 4950 lbs. |
| Dynamic Radial Load Capacity | 4945 lbf. |
| Finish | None |
| Grade | Grade 52100 |
| Housing Material | Polymer |
| Housing Material Grade | PBT |
| Inner Ring Width | 1.688" |
| Insert | Ball Bearing |
| Insert Finish | Chrome Plated |
| Insert Material | Steel |
| Insert Type | Ball |
| Lock Type | Set Screw |
| Lubricant Material | FDA, USDA-H1 Solid Grease |
| Material | Steel |
| Max. Temp. | 212°F |
| Min. Temp. | -4°F |
| Mount Hole Center To Center Length | 5" |
| Mount Hole Size | 0.551" |
| Mounting Bolt Size | M10 |
| Mounting Hole Center | 127 mm |
| Mounting Surface To Shaft Center | 47.6 mm |
| Mounting Surface To Shaft Center Height | 1 55/64" |
| Mounting Type | Bolt Through |
| No. Of Bolts | 2 |
| No. Of Mount Holes | 2 |
| Overall Height | 3.687" |
| Overall Length | 6.562" |
| Overall Width | 1 7/8" |
| Resistance Properties | Corrosion Resistant |
| Seal Type | Contact |
| Shaft Locking Type | Set Screw |
| Static Load Capacity | 2770 lbs. |
| Static Radial Load Capacity | 2765 lbf. |
| Temp. | -4°F to +230°F |
| Type | Ball |
Shipping Info:
| Ship weight (kg) | 0.9 |
| Ship height (cm) | 9.36 |
| Ship length (cm) | 16.67 |
| Ship width (cm) | 4.76 |
| HS code | 8483204040 |
| Country of Origin | FR |
Product Variants
| Model | Housing Material | Bore Dia. | Overall Width | Overall Height | Overall Length | Shaft Locking Type | Mounting Bolt Size | Closure | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| SUCFL206-20 | Stainless Steel | 1 1/4" | 1 37/64" | 3 9/64" | 5 17/32" | Set Screw | 1/2" | Double Sealed | €454.93 | |
| SUCFL207-22 | Stainless Steel | 1 3/8" | 1 3/4" | 3 33/64" | 5 1/8" | Set Screw | 1/2" | Double Sealed | €565.82 | |
| SUCFL207-22 | Stainless Steel | 1 3/8" | 1 3/4" | 3 33/64" | 5 1/8" | Set Screw | 1/2" | Double Sealed | €584.99 | |
| SUCFL207-23 | Stainless Steel | 1 7/16" | 1 3/4" | 44.4 mm | 5 1/8" | Set Screw | 1/2" | Double Sealed | €584.99 | |
| SUCF205-16N | Stainless Steel | 1" | 1 13/32" | 3 3/4" | 3 3/4" | Set Screw | 3/8" | Double Sealed | €313.00 | |
| SUCF206-20 | Stainless Steel | 1 1/4" | 1 37/64" | 4 1/4" | 4 1/4" | Set Screw | 3/8" | Double Sealed | €473.75 | |
| SUCF207-22 | Stainless Steel | 1 3/8" | 1 3/4" | 4 19/32" | 4 19/32" | Set Screw | 1/2" | Double Sealed | €597.75 |
