NORGREN M24680418 Swivel Side Tee Tube 1/4 Inch
Item: AB2FFBModel: M24680418Cross Ref: 1LRW4
7 In Stock
Ships within 2 days via
10.00% off
€70.24 /pkg. of 10
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Swivel Side Tee |
| Application | Air |
| Basic Material | Plastic |
| Body Material | Polybutylene |
| Color | Gray |
| Compatible Tube Material | Nylon, Polyurethane |
| Connection Type | Tube x MNPT |
| Finish/coating | Nickel Plated |
| Fitting Material | Brass, PBT |
| Fitting Side A Connection Type | Push-To-Connect |
| Fitting Side A Tube Outer Diameter | 1/8" |
| Fitting Side B Connection Type | Push-To-Connect |
| Fitting Side B Tube Outer Diameter | 1/4" |
| Fitting Side C Connection Type | MNPT |
| Fitting Side C Pipe Size | 1/4" |
| Hex Size | 0.438" |
| Includes Pre-applied Thread Sealant | Yes |
| Max. Pressure | 150 psi |
| Maximum Operating Pressure | 150 psi |
| Maximum Operating Temperature | 140°F |
| Minimum Operating Temperature | 32°F |
| Pipe Size | 1/8" |
| Release Ring Color | Gray |
| Release Ring Material | Stainless Steel |
| Release Type | Button |
| Resistance Properties | Impact Resistant |
| Specific Fitting Shape | Tee |
| System Of Measurement | Imperial |
| Temp. Range | +32°F to +140°F |
| Thread Sealant Type | Chemiseal G 175 |
| Tube Size | 1/4" |
| Vacuum Rating | 29.5 in. hg |
Shipping Info:
| Ship weight (kg) | 0.14 |
| Ship height (cm) | 9.65 |
| Ship length (cm) | 16 |
| Ship width (cm) | 11.18 |
| HS code | 3917400090 |
| Country of Origin | KR |
Product Variants
| Model | Fitting Side A Connection Type | Fitting Side B Connection Type | Hex Size | Fitting Side B Tube Outer Diameter | Vacuum Rating | Thread Sealant Type | Fitting Side C Pipe Size | Tube Size | Pkg. Qty. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| M01680418 | Tube | Tube | 14 mm | 4 mm | 750 mm hg | Chemitech G | 1/8" | 4 mm | 10 | €105.97 | |
| M02680606 | Tube | Tube | 8 mm | 6 mm | 750 mm hg | Chemitech G | 1/4" | 6 mm | 10 | €138.27 | |
| M24680118 | Push-To-Connect | Push-To-Connect | 0.438" | 1/8" | 29.5 in. hg | Chemiseal G 175 | 1/8" | - | 10 | €84.08 | |
| M24680210 | UNF | Tube | 0.312" | 5/32" | 29.5 in. hg | Chemiseal G 175 | 5/32" | 0.156" | 10 | €88.91 | |
| M24680410 | UNF | Tube | 0.312" | 1/4" | 29.5 in. hg | Chemiseal G 175 | 1/4" | 1/4" | 10 | €88.96 |
