MERSEN FERRAZ TRM2 Fuse, 250VAC, 2A, 1 Pole
Item: AG8WQAModel: TRM2Cross Ref: 540N55
7 In Stock
Ships within 2 days via
5.00% off
€12.21 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Fuse |
| Ac Max I.r./breaking Capacity I1 | 10 kA |
| Ac Voltage | 250V AC |
| Ac/dc | AC |
| Amps | 2A |
| Amps Rating | 2A |
| Body Material | GMG |
| Body Style | Cartridge Fuses |
| Body/insulating Material | GMG |
| Class | Midget |
| Connection/terminal Material | Copper |
| Connection/terminal Type | Ferrule |
| Diameter | 0.41" |
| Finish | Tin Plated |
| Frame Type | TRM |
| Frequency | 50/60 Hz |
| Fuse Class | Midget |
| Fuse Type | Time Delay/Slow Blow |
| Indicator Included | No |
| Interrupt Rating | 10 kA at 250V AC |
| Length | 1.5" |
| Mounting | Clip |
| Mounting Style | Holder |
| Number Of Poles | 1 |
| Product Datasheet | mersen-ferraz-trm1.pdf |
| Product Group | Low Voltage UL/CSA Fuses |
| Rated Voltage Ac Ul | 250V AC |
| Rohs Compliant | Yes |
| Speed Characteristic | Time Delay |
| Speed Type | Time Delay |
| Termination Style | Clip |
| Type | Cartridge Fuse |
| Voltage | 250V |
| Voltage Rating | 250V AC |
| Voltage Type | AC |
Shipping Info:
| Ship weight (kg) | 0.01 |
| Ship height (cm) | 5.38 |
| Ship length (cm) | 3.81 |
| Ship width (cm) | 1.04 |
| Country of Origin | MX |
Documentation:
Product Variants
| Product | Model | Amps | Diameter | Interrupt Rating | Fuse Type | Body Material | Body Style | Amps Rating | Mounting | Pkg. Qty. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
TRM1 | 1A | 0.41" | 10 kA at 250V AC | Time Delay/Slow Blow | - | Cartridge Fuses | 1A | Clip | 1 | €12.04 | |
 |
TRM1/10 | 0.1A | 10.3 mm | - | Midget | GMG | - | - | Clip | 1 | €11.78 | |
 |
TRM1/2 | 0.5A | 10.3 mm | - | Midget | GMG | - | - | Clip | 1 | €11.78 | |
 |
TRM1/4 | 0.25A | 10.3 mm | - | Midget | GMG | - | - | Clip | 1 | €13.93 | |
 |
TRM10 | 10A | 0.41" | 10 kA at 250V AC | Time Delay/Slow Blow | GMG | Cartridge Fuses | 10A | Clip | 1 | €12.04 | |
 |
TRM1-1/8 | 1.125A | 10.3 mm | - | Midget | GMG | - | - | Clip | 1 | €11.78 | |
 |
TRM12 | 12A | - | - | - | - | - | - | - | 1 | €12.85 |
