MERSEN FERRAZ 32033T Fuse Base, 300V, 200A, Class T, 3 Pole, Tin Plated, Aluminium Box
Item: CH4RAMModel: 32033TCross Ref: 5LDG6
7 In Stock
Ships within 2 days via
5.00% off
€579.64 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Fuse Base |
| Ac Voltage Rating | 300V AC |
| Ac/dc | AC/DC |
| Amps | 101-200A , 200A |
| Body Material | Glass Filled Polycarbonate |
| Body/insulating Material | Phenolic |
| Connector Type | Box Lug |
| Features | Unique Adder Block Design |
| Fits Fuse Type | Industrial |
| For Fuse Size | 2 7/16" x 1 1/16" Dia., 2 7/16" x 7/8" Dia. |
| Frequency | 50/60 Hz |
| Fuse Block Design | Open |
| Fuse Block Style | Nonrejection |
| Fuse Class | Class T |
| Fuse Installation Method | Clip In |
| Fuse Ul Class | Class T |
| Height | 66 mm |
| Installation Mounting | Direct Screw Mount |
| Length | 152.4 mm |
| Max. Fuse Rating | 200A |
| Mounting Style | Bolt Down |
| No. Of Poles | 3 |
| Product Datasheet | mersen-ferraz-30305t.pdf |
| Product Group | Fuse Bases |
| Rated Voltage Ac Ul | 300V |
| Rated Voltage Dc Ul | 300V |
| Rohs Compliant | Yes |
| Short Circuit Amps Rating (sccr) | 200 kA |
| Spring Reinforced Clip | Yes |
| Torque | 31.071 N-m |
| Visual Indication | Non Indicating |
| Voltage | 300V AC/DC |
| Width | 152.4 mm |
| Wire | 350 mcm |
Shipping Info:
| Ship weight (kg) | 1.58 |
| Ship height (cm) | 6.2 |
| Ship length (cm) | 18.08 |
| Ship width (cm) | 18.08 |
| Country of Origin | MX |
Product Details:
- With Reinforced Clip
Documentation:
Product Variants
| Product | Model | Amps | Height | No. Of Poles | Body/insulating Material | Torque | Max. Fuse Rating | Ac Voltage Rating | For Fuse Size | Pkg. Qty. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
30305T | 30A | 37.3 mm | Adder | Glass Filled Polycarbonate | 3.954 N-m | 30A | 300V AC | - | 5 | €172.98 | |
 |
30306T | 30A | 37.3 mm | 1 | Glass Filled Polycarbonate | 3.954 N-m | 30A | 300V AC | - | 5 | €185.53 | |
 |
30307T | 30A | 37.3 mm | 2 | Glass Filled Polycarbonate | 3.954 N-m | 30A | 300V | 7/8" x 13/32" | 1 | €45.38 | |
 |
30308T | 30A | 37.3 mm | 3 | Glass Filled Polycarbonate | 3.954 N-m | 30A | 300V AC | 7/8" x 13/32" | 1 | €91.36 | |
 |
30309T | 30A | 37.3 mm | 4 | Glass Filled Polycarbonate | 3.954 N-m | 30A | 300V AC | - | 1 | €134.29 | |
|
30315T | 30A | 37.3 mm | Adder | Glass Filled Polycarbonate | 2.26 N-m | 30A | 300V AC | - | 5 | €143.22 | |
 |
30316T | 30A | 37.3 mm | 1 | Glass Filled Polycarbonate | 2.26 N-m | 30A | 300V AC | - | 5 | €149.22 |
