MARATHON MOTORS LM30093 SSD2P15/20T6006YEH2 Elevator Duty Motor, 15 and 20 HP, 3 Ph, 60 Hz, 200 and 200V, 3600 and 3600 RPM
Get it by Thursday, Feb 26
€1,873.81 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Definite Purpose Motor |
| Ambient Temp. | 40°C |
| Amps | 39/53A |
| Assembly/box Mounting | F1 Only |
| Code | G |
| Design Code | Inv |
| Drive End Bearing Size | 6307 |
| Drive End Bearing Type | Ball |
| Efficiency | 90.2% |
| Electrical Type | Squirrel Cage, Induction Run |
| Enclosure Type | ODP |
| Frame | 215T |
| Frame Length | 12 2/5" |
| Frame Material | Rolled Steel |
| Frame Size | 215T |
| Frequency | 60 Hz |
| Full Load Amps | 39/53A |
| Hp | 15 hp |
| Insulation Class | Class F |
| Ip Code | IP22 |
| Kva Code | G |
| Kw | 11.2 kW |
| Motor Enclosure Design | Dripproof |
| Motor Orientation | Horizontal |
| Motor Shaft Rotation | Clockwise/Counter Clockwise |
| Mounting Type | Rigid Base |
| Nameplate Rpm | 3600 RPM |
| Nema Design | G |
| No. Of Poles | 2 |
| No. Of Speeds | 1 |
| Opp. Drive End Bearing Size | 6206 |
| Opp. Drive End Bearing Type | Ball |
| Output Kw | 11.2/14.9 kW |
| Overall Length | 18.54" |
| Packaging | B |
| Phase | 3 |
| Power | 11.2 kW |
| Power Factor | 91 |
| Resistance Main | 0 ohms |
| Rotation Type | Reversible |
| Rpm | 3400-3600 RPM |
| Service Factor | 1 |
| Shaft Dia. | 1 3/8" |
| Shaft Length | 3.38" |
| Shaft Type | T |
| Starting Method | Wye Start Delta Run |
| Thermal Protection | No Protection |
| Type | TDR |
| Voltage | 200V |
Shipping Info:
| Ship weight (kg) | 60.75 |
| Ship height (cm) | 35.56 |
| Ship length (cm) | 57.15 |
| Ship width (cm) | 42.7 |
| Country of Origin | US |
Product Details:
- Bearing OPE: 6206
- CC Number: EXEMPT
- Bearing PE: 6307
- Nameplate: 91554
- Winding: K2152149
- GROUP: 7
- Paint: GRAY - GE
- Eff 100%: 90.2 / 88.5
