MARATHON MOTORS B199742.00 C215T34DK49A General Purpose Motor, Drip Proof, 15 HP, 3 Phase, 60 Hz, 230/460V
Get it by Tuesday, Aug 25
€1,342.38 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | General Purpose Motor |
| Amps | 36/18/29.8/14.9A |
| Amps Rating | 36/18A |
| Composition | Steel |
| Design Code | B |
| Dimension S | 18.1" x 12.23" x 11.02" |
| Drive End Bearing Size | 6307 |
| Duty Cycle | Continuous |
| Efficiency | 90.2% |
| Electrical Type | Squirrel Cage Inverter Rated |
| Enclosure | Open Dripproof |
| Family Series | Leeson Motors |
| Frame Length | 11.15" |
| Full Load Amps | 36A |
| Height | 16 21/25" |
| Hp | 15 hp |
| Insulation Class | Class F3 |
| Kva Code | G |
| Kw | 11.2 kW |
| Length | 19.47" |
| Motor Orientation | Horizontal |
| Mounting | Rigid Base |
| Mounting Type | Rigid |
| No. Of Speeds | 1 |
| Nominal Voltage | 240/480V AC |
| Opp Drive End Bearing Size | 6206 |
| Overall Length | 18.1" |
| Phase | 3 |
| Power Factor | 86 |
| Product Datasheet | leeson-b199742-00.pdf |
| Resistance Main | 0.97 ohms |
| Rotation | Reversible |
| Service Factor | 1.15 |
| Shaft Dia. | 1.375 |
| Shaft Extension | 3.38" |
| Shaft Length | 3.38 |
| Shaft Size | 1.375" x 3.38" |
| Shaft Type | T |
| Speed | 2930 RPM , 3400-3600 RPM |
| Thermal Protection | NO Protection |
| Type | 2 Pole Squirrel Cage Inverter Rated |
| Voltage | 230/460V |
| Voltage Ac | 230/460V AC |
| Width | 13 3/5" |
Shipping Info:
| Ship weight (kg) | 77.4 |
| Ship height (cm) | 42.77 |
| Ship length (cm) | 49.45 |
| Ship width (cm) | 34.54 |
| Country of Origin | CN |
