MARTIN SPROCKET QD Bushed Type High Torque Sprockets, 8MM Belt Pitch
Filter
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
X
Y
Z
A1
B1
C1
D1| Style | Model | Bore Dia. | Pitch Dia. | Outside Dia. | Face Width | Type | Pitch | Bushing Type | Flange Dia. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | P368M50-SH | - | - | - | - | - | - | - | - | €284.61 | |
| B | P388M85-SH | 0.5" to 1.688" | 3.81" | 3.758" | 3 3/4" | Solid Type AF-1 | 0.31496" | SH | 4.134" | €341.53 | |
| C | P408M50-SH | 0.5" to 1.688" | 4.01" | 3.956" | 2 3/8" | Solid Type AF-1 | 8 mm | SH | 4.344" | €294.65 | |
| D | P408M30-SH | 0.5" to 1.688" | 4.01" | 3.956" | 1 1/4" | Solid Type AF-1 | 8 mm | SH | 4 3/4" | €261.16 | |
| D | P408M20-SH | 0.5" to 1.688" | 4.01" | 3.956" | 7/8" | Solid Type DF-1 | 8 mm | SH | 4.344" | €227.68 | |
| D | P388M50-SH | 0.5" to 1.688" | 3.81" | 3.756" | 2 1/8" | Solid Type AF-1 | 8 mm | SH | 4.156" | €287.94 | |
| D | P388M30-SH | 0.5" to 1.688" | 3.8095" | 3.756" | 1 1/4" | Solid Type AF-1 | 8 mm | SH | 4.156" | €234.38 | |
| E | P368M85-SH | 0.5" to 1.688" | 3.609" | 3.557" | 3 3/4" | Solid Type AF-1 | 0.31496" | SH | 3.937" | €334.82 | |
| D | P388M20-SH | 0.5" to 1.688" | 3.81" | 3.756" | 2 1/8" | Solid Type DF-1 | 8 mm | SH | 3.938" | €214.27 | |
| F | P368M30-SH | 0.5" to 1.688" | 3.609" | 3.555" | 1 1/4" | Solid Type AF-1 | 8 mm | SH | 3.938" | €227.68 | |
| E | P368M20-SH | 0.5" to 1.688" | 3.609" | 3.555" | 1 1/8" | Solid Type DF-1 | 8 mm | SH | 3.937" | €207.58 | |
| E | P348M85-SH | 0.5" to 1.688" | 3.409" | 3.357" | 3 3/4" | Solid Type AF-1 | 0.31496" | SH | 3.819" | €318.07 | |
| G | P348M50-SH | 0.5" to 1.688" | 3.409" | 3.355" | 2 1/8" | Solid Type AF-1 | 8 mm | SH | 2 3/8" | €281.24 | |
| H | P348M30-SH | 0.5" to 1.688" | 3.409" | 3.355" | 2 1/8" | Solid Type AF-1 | 8 mm | SH | 2 3/8" | €210.95 | |
| E | P348M20-SH | 0.5" to 1.688" | 3.409" | 3.355" | 1 1/8" | Solid Type DF-1 | 8 mm | SH | 3 3/4" | €200.89 | |
| I | P1128M50-SF | 0.5" to 2.938" | 11.229" | 11.175" | 2 3/8" | Spoked Type D-3 | 8 mm | SF | - | €671.53 | |
| J | P1448M30-SF | 0.5" to 2.938" | 14.437" | 14.383" | 1 1/2" | Spoked Type C-3 | 8 mm | SF | - | €648.59 | |
| E | P648M85-SF | 0.5" to 2.938" | 6.416" | 6.3645" | 3 3/4" | Solid Type AF-1 | 0.31496" | SF | 6 3/4" | €467.78 | |
| K | P1448M20-SF | 0.5" to 2.938" | 14.437" | 14.3865" | 1 1/8" | Arms Type C-3 | 0.31496" | SF | - | €642.87 | |
| L | P1128M85-F | 1" to 4" | 11.229" | 11.178" | 3 3/4" | Arms Type A-3 | 0.31496" | F | - | €883.91 | |
| M | P1448M85-F | 1" to 4" | 14.437" | 14.3865" | 3 3/4" | Arms Type A-3 | 0.31496" | F | - | €1,234.04 | |
| K | P1928M85-F | 1" to 4" | 19.249" | 19.1985" | 3 3/4" | Arms Type A-3 | 0.31496" | F | - | €1,391.88 | |
| N | P648M50-SK | 1/2" to 2 5/8" | 6.416" | 6.362" | 2 3/8" | Solid Type DF-1 | 8 mm | SK | 6 3/4" | €435.27 | |
| K | P1128M20-SK | 1/2" to 2 5/8" | 11.229" | 11.178" | 1 1/8" | Arms Type C-3 | 0.31496" | SK | - | €528.06 | |
| O | P1128M30-SK | 1/2" to 2 5/8" | 11.229" | 11.175" | 1 1/2" | Spoked Type C-3 | 8 mm | SK | - | €533.81 | |
| P | P728M50-SK | 1/2" to 2 5/8" | 7.218" | 7.164" | 2 3/8" | Solid Type DF-1 | 8 mm | SK | 7.562" | €413.27 | |
| E | P728M30-SK | 1/2" to 2 5/8" | 7.218" | 7.167" | 1 1/2" | Solid Type CF-1 | 0.31496" | SK | 7.562" | €396.03 | |
| Q | P568M50-SK | 1/2" to 2 5/8" | 5.614" | 5 14/25" | 2 3/8" | Solid Type DF-1 | 8 mm | SK | 5.937" | €385.04 | |
| E | P568M85-SK | 1/2" to 2 5/8" | 5.614" | 5 14/25" | 3 3/4" | Solid Type AF-1 | 8 mm | SK | 5.937" | €468.75 | |
| D | P808M50-SF | 1/2" to 2 7/8" | 8.02" | 7.966" | 2 5/8" | Solid Type DF-1 | 8 mm | SF | 8 3/8" | €444.82 | |
| R | P908M50-SF | 1/2" to 2 7/8" | 9.023" | 8.969" | 2 3/8" | Solid Type D-2 | 8 mm | SF | - | €533.81 | |
| D | P488M20-SDS | 1/2" to 2" | 4.812" | 4.758" | 7/8" | Solid Type CF-1 | 8 mm | SDS | 5.16" | €308.04 | |
| E | P408M85-SD | 1/2" to 2" | 4.01" | 3.958" | 3 3/4" | Solid Type AF-1 | 0.19685" | SD | 4.344" | €354.90 | |
| E | P448M20-SDS | 1/2" to 2" | 4.411" | 4.357" | 1 1/8" | Solid Type CF-1 | 8 mm | SDS | 4 3/4" | €264.50 | |
| S | P448M30-SDS | 1/2" to 2" | 4.411" | 4.357" | 1 1/4" | Solid Type BF-1 | 8 mm | SDS | 5.16" | €287.94 | |
| T | P448M50-SD | 1/2" to 2" | 4.411" | 4.357" | 2 3/8" | Solid Type AF-1 | 8 mm | SD | 4 3/4" | €314.74 | |
| U | P808M20-SDS | 1/2" to 2" | 8.02" | 7.966" | 1 1/8" | Type CF-2 Web | 8 mm | SDS | 8 3/8" | €462.03 | |
| E | P488M85-SD | 1/2" to 2" | 4.812" | 4.7605" | 3 3/4" | Solid Type AF-1 | 0.31496" | SD | 5.157" | €401.79 | |
| V | P448M85-SD | 1/2" to 2" | 4.411" | 4.3595" | 3 3/4" | Solid Type AF-1 | 0.31496" | SD | 4 3/4" | €368.28 | |
| D | P488M30-SDS | 1/2" to 2" | 4.812" | 4.758" | 1 1/4" | Solid Type BF-1 | 8 mm | SDS | 2 3/4" | €311.38 | |
| W | P908M20-SDS | 1/2" to 2" | 9.023" | 8.972" | 1 1/8" | Web Type C-2 | 0.31496" | SDS | - | €475.43 | |
| D | P488M50-SD | 1/2" to 2" | 4.812" | 4.758" | 2 3/4" | Solid Type AF-1 | 8 mm | SD | 5.156" | €328.12 | |
| D | P648M30-SK | 1/2" to 2" | 6.416" | 6.362" | 1 1/2" | Solid Type DF-1 | 8 mm | SK | 6 3/4" | €421.86 | |
| X | P728M20-SDS | 1/2" to 2" | 7.218" | 7.164" | 1 1/8" | Solid Type CF-1 | 8 mm | SDS | 7.562" | €428.57 | |
| Y | P568M30-SDS | 1/2" to 2" | 5.614" | 5 14/25" | 1 1/4" | Solid Type BF-1 | 8 mm | SDS | 5.945" | €348.21 | |
| Z | P568M20-SDS | 1/2" to 2" | 5.614" | 5 14/25" | 7/8" | Solid Type CF-1 | 8 mm | SDS | 5.945" | €341.53 | |
| E | P648M20-SDS | 1/2" to 2" | 6.416" | 6.3645" | 1 1/8" | Solid Type CF-1 | 0.31496" | SDS | 6 3/4" | €418.54 | |
| D | P288M20-H | 3/8" to 1 1/2" | 2.807" | 2.753" | 7/8" | Solid Type EF-1 | 8 mm | H | 3.156" | €184.16 | |
| E | P288M30-H | 3/8" to 1 1/2" | 2.807" | 2.759" | 1 1/2" | Reverse Mount Solid Type EF-1 | 8 mm | H | 3.156" | €197.53 | |
| D | P308M20-H | 3/8" to 1 1/2" | 3.008" | 2.954" | 7/8" | Solid Type EF-1 | 8 mm | H | 3.345" | €190.84 | |
| E | P308M30-H | 3/8" to 1 1/2" | 3.008" | 2.958" | 1 1/2" | Reverse Mount Solid Type EF-1 | 8 mm | H | 3.344" | €200.89 | |
| D | P328M20-H | 3/8" to 1 1/2" | 3.208" | 3.154" | 7/8" | Solid Type CF-1 | 8 mm | H | 3.562" | €197.53 | |
| D | P328M30-H | 3/8" to 1 1/2" | 3.208" | 3.154" | 7/8" | Solid Type BF-1 | 8 mm | H | 3.562" | €207.58 | |
| D | P328M50-H | 3/8" to 1 1/2" | 3.208" | 3.154" | 7/8" | Solid Type AF-1 | 8 mm | H | 3.562" | €277.91 | |
| D | P248M20-JA | 3/8" to 1 1/4" | 14.447" | 14.383" | 2 3/8" | Solid Type EF-1 | 8 mm | JA | 2 3/4" | €177.46 | |
| E | P268M20-JA | 3/8" to 1 1/4" | 2.607" | 2.553" | 1 1/8" | Reverse Mount Solid Type EF-1 | 8 mm | JA | 2.937" | €180.79 | |
| A1 | P808M85-E | 7/8" to 2 15/16" | 8.02" | 7.966" | 3 3/4" | Solid Type AF-1 | 8 mm | E | 8 3/8" | €556.77 | |
| B1 | P908M85-E | 7/8" to 2 15/16" | 9.023" | 8.969" | 3 3/4" | Solid Type A-2 | 8 mm | E | - | €703.11 | |
| C1 | P1928M50-E | 7/8" to 8 3/4" | 19.249" | 14.383" | 5 1/4" | Spoked Type D-3 | 8 mm | E | - | €1,239.78 | |
| D1 | P1448M50-E | 7/8" to 8 3/4" | 14.437" | 14.3865" | 2 3/8" | Arms Type D-3 | 0.31496" | E | - | €1,070.46 | |
| E | P728M85-E | 7/8" to 8 3/4" | 7.218" | 7.167" | 3 3/4" | Solid Type AF-1 | 0.31496" | E | 7.562" | €507.96 |
