MADISON MS5917 Liquid Level Switch 1/4 Inch Npt Selectable 316 Stainless Steel
Item: AC4HVLModel: MS5917Cross Ref: 2ZY41
7 In Stock
Ships within 2 days via
10.00% off
€127.27 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Liquid Level Switch |
| Body Material | Stainless Steel |
| Components Included | Float |
| Conduit Size | 1/4" |
| Contact Form | SPST |
| Current Rating | 0.5A |
| Display Qty | 1 |
| Electrical Connection Type | Lead Wires |
| Finish | Coat |
| Float Dia. | 2.13" |
| Float Length | 2.00" |
| Float Length | 2" |
| Float Material | Stainless Steel |
| Float Specific Gravity | 0.55 |
| Float Switch Float Material | Stainless Steel |
| Gauge | 18 ga. |
| Grade | Grade 316 |
| Height | 3.38" |
| Max. Current | 0.5A |
| Max. Current | 0.50A |
| Max. Pressure | 200 psi |
| Max. Voltage | 240V |
| Minimum Media Specific Gravity | 0.55 xg |
| Mounting | Vertical Open Tank |
| Mounting Position | Vertical |
| Mounting Style | Open Tank Vertical |
| Operating Temp. | 482°F |
| Operating Temperature - Maximum | 482°F |
| Overall Height | 3.38" |
| Overall Length | 3.38" |
| Overall Width | 3.38" |
| Product Type | Alternator Closed Liquid Level Switch |
| Proof Pressure | 200 psi |
| Standards | CSA |
| Stem Length | 2.63" |
| Stem Material | Stainless Steel |
| Stem Thread Size | 1/4" |
| Switch Action | Select |
| Switch Function | Select |
| Tank Connection Size | 1/4" NPT |
| Thread Type | NPT |
| Voltage Rating - Maximum | 240V AC |
| Width | 3.38" |
Shipping Info:
| Ship weight (kg) | 0.27 |
| Ship height (cm) | 8.59 |
| Ship length (cm) | 8.59 |
| Ship width (cm) | 8.59 |
| HS code | 9032896060 |
| Country of Origin | US |
Product Variants
| Product | Model | Contact Form | Float Material | Float Length | Float Dia. | Body Material | Operating Temp. | Mounting | Max. Current | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
MS5010 | SPST | Stainless Steel | 1.19" | 1.13" | Stainless Steel | 392°F | Side | 0.28A | €164.03 | |
 |
MS7000 | SPST | Buna N | 1" | 1" | PBT | 221°F | Vertical Open Tank | 0.28A | €38.24 | |
 |
MS8000 | SPST | Polypropylene | 1" | 1" | Polypropylene | 221°F | Vertical Open Tank | 0.28A | €39.27 | |
 |
MS8800 | SPST | Polypropylene | 2.68" | 1 1/2" | Polypropylene | 221°F | Vertical Open Tank | 0.5A | €89.10 | |
 |
MS9000 | SPST | Kynar | 1" | 1" | Kynar | 221°F | Vertical Open Tank | 0.28A | €52.41 | |
 |
MSB5600 | SPST | Stainless Steel | 2.5" | 2.13" | Stainless Steel | 221°F | Vertical Open Tank | 0.5A | €257.53 | |
 |
M4190 | SPDT | Stainless Steel | 4" | 1" | Stainless Steel | 302°F | Side | 1A | €494.99 |
