MACROMATIC SFF240A100 Pump Seal Failure Relay, 240VAC, 10A
Get it by Monday, Aug 17
€197.12 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Protection Relay |
| Amps Supported | 10A |
| Amps Unbalance Detect | No |
| Contact Failure Detect | No |
| Display Type | LED Status Indicator |
| Family Series | Macromatic Protection Relays, SFF Series |
| Gross Weight | 0 lbs. |
| High Power Over Voltage Trip | No |
| Input Voltage | 240V AC |
| Line Voltage | 240V |
| Lo Hp Trip Detect | No |
| Lo Kw Trip Detect | No |
| Lo Pwr (under Vltg) Trip | No |
| Manual Reset | No |
| Mounting | Flange |
| No. Of Phase | 1 |
| Output Amps | 10A |
| Output Relay | SPDT |
| Over Amps | No |
| Phase Loss Detect | No |
| Phase Rvrse/rotatn Detect | No |
| Rapid Cycling Detect | No |
| Restart Delay | 1 sec. |
| Series | SFF Series |
| Time Delay Trip | 1 sec. |
| Type Of Display | LED Status Indicator |
| Under Amps Detect | No |
| Var Restart Delay | No |
| Variable Point Trip | No |
| Voltage Unbalance Detect | No |
Shipping Info:
| Ship weight (kg) | 0.31 |
| Ship height (cm) | 6.1 |
| Ship length (cm) | 7.37 |
| Ship width (cm) | 4.32 |
Product Variants
| Product | Model | Input Voltage | Output Amps | Line Voltage | No. Of Phase | Amps Supported | Mounting | Time Delay Trip | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
 |
SFF024A100 | 24V AC | 10A | 24V | 1 | 10A | Flange | 1 sec. | €197.12 | |
 |
SFF024A250 | 24V AC | 10A | 24V | 1 | 10A | Flange | 1 sec. | €197.12 | |
 |
SFF024C100 | 24V AC | 5A | 24V | 1 | 10A | Flange | 1 sec. | €224.98 | |
 |
SFF024C250 | 24V AC | 5A | 24V | 1 | 10A | Flange | 1 sec. | €224.98 | |
 |
SFF120A100 | 120V AC | 10A | 120V | 1 | 10A | Flange | 1 sec. | €197.12 | |
 |
SFF120A250 | 120V AC | 10A | 120V | 1 | 10A | Flange | 1 sec. | €197.12 | |
 |
SFF120C100 | 120V AC | 5A | 120V | 1 | 10A | Flange | 1 sec. | €224.98 |
