LOVEJOY 68514477232 Disc Coupling, 80 Inch Lbs Torque, 1.969 Inch Dia., 0.0280 Lbs Inch Sq. Inertia
Get it by Thursday, Dec 25
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Disc Coupling |
| Angular Misalignment | 1.5° |
| Axial Misalignment | -0.2" to +0.2" |
| Bore A | 1/2" x 5/8" |
| Bore B | 1/2" x 5/8" |
| Bore Type | Finished Bore |
| Clamp Screw Size | M3 |
| Coupling Size | MD50C |
| Coupling Type | Mini Disc Coupling |
| Coupling Weight (lb.) | 7.41 oz. |
| Disc Material | Stainless Steel |
| Hub Material | Aluminum |
| Keyway | Without Keyway |
| Length Through Bore | 0.709" |
| Max. Bore Dia. | 0.984" |
| Max. Operating Temp. | 300°F |
| Max. Speed | 4000 RPM |
| Min. Bore | 0.551" |
| Moment Of Inertia | 0.028 lbs.-sq. in. |
| Nominal Torque | 80 lbs.-in. |
| Outside Dia. | 1.969" |
| Overall Length | 2.244" |
| Parallel Misalignment | 0.006" |
| Product Datasheet | lovejoy-68514456618.pdf |
| Series | MD Series |
| Style | Clamp Screw |
| System Of Measurement | Imperial |
| Torsional Stiffness | 19470 lbs.-in./rad |
| Volume | 8.6999 cu. in. |
Shipping Info:
| Ship weight (kg) | 0.21 |
Documentation:
Product Variants
| Model | Overall Length | Torsional Stiffness | Parallel Misalignment | Max. Speed | Moment Of Inertia | Coupling Size | Nominal Torque | Clamp Screw Size | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| 68514477216 | 1.22" | 3983 lbs.-in./deg. | 0.005" | 8000 RPM | 0.009 lbs.-sq. in. | MD25C | 9 lbs.-in. | M2.5 | €263.54 | RFQ
|
| 68514477210 | 1.063" | 1770 lbs.-in./rad | 0.005" | 10000 RPM | 0.003 lbs.-sq. in. | MD19C | 6 lbs.-in. | M2 | - | RFQ
|
| 68514477211 | 1.063" | 1770 lbs.-in./rad | 0.005" | 10000 RPM | 0.003 lbs.-sq. in. | MD19C | 6 lbs.-in. | M2 | - | RFQ
|
| 68514477212 | 1.063" | 1770 lbs.-in./rad | 0.005" | 10000 RPM | 0.003 lbs.-sq. in. | MD19C | 6 lbs.-in. | M2 | - | RFQ
|
| 68514477213 | 1.063" | 1770 lbs.-in./rad | 0.005" | 10000 RPM | 0.003 lbs.-sq. in. | MD19C | 6 lbs.-in. | M2 | - | RFQ
|
| 68514477214 | 1.22" | 3983 lbs.-in./rad | 0.005" | 8000 RPM | 0.009 lbs.-sq. in. | MD25C | 9 lbs.-in. | M2.5 | - | RFQ
|
| 68514477215 | 1.22" | 3983 lbs.-in./rad | 0.005" | 8000 RPM | 0.009 lbs.-sq. in. | MD25C | 9 lbs.-in. | M2.5 | €341.98 |
