LITTLE GIANT PUMPS 2343362604G 4C3F(3HP /575 /60 /W)900lb Submersible Pump Motor, 3 HP, 3450 Nameplate RPM, 575VAC, 3 Wires, CCW
Item: CR9QPBModel: 2343362604GCross Ref: 801C71 / 4C3F(3HP /575 /60 /W)900lb
In Stock
Get it by Tuesday, Aug 25
5.00% off
€1,385.49 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Pump Motor |
| Bearing Type | Kingsbury |
| Body Dia. | 3 4/5" |
| Bolt Circle Dia. | 2 7/8" |
| Cord Length | 4 ft. |
| Diaphragm Type | Pressure Equalizing |
| Duty Cycle | Continuous |
| Frequency | 60 Hz |
| Full Load Amps | 3.8A |
| Height | 16 13/16" |
| Hp | 3 hp |
| Ins. Class | Class B |
| Lead Length | 4 ft. |
| Length Less Shaft | 15.29" |
| Max. Ambient Temp. | 86°F |
| Max. Overload Relay Amps Setting | 4.4A |
| Max. Sf Amps | 4.4A |
| Motor Application | Pumps |
| Motor Bearings | Kingsbury |
| Motor Design | 3 Phase |
| Motor Enclosure Design | Hermetically Sealed |
| Motor Mounting Position | Vertical Shaft Up |
| Motor Mounting Type | Nema Pump Mounting |
| Motor Service Factor | 1.15 |
| Motor Shaft Design | Splined |
| Motor Shaft Rotation | CCW |
| Motor Sub Application | Water Wells |
| Motor Thermal Protection | Built In Lightning Arrestor |
| Mounting Type | NEMA Pump Mounting |
| Nameplate Speed | 3450 RPM |
| No. Of Wires | 3 |
| Overall Length | 16 1/16" |
| Overload Relay Amps Setting | 3.8A |
| Overload Relay Required | No |
| Phase | 3 |
| Service Factor | 1.15 |
| Shaft Material | Nitrile Rubber |
| Starter Required | No |
| Stator Type | Hermetically Sealed |
| Thermal Protection | Built In Lightning Arrestor |
| Thrust Rating | 900 lbs. |
| Voltage | 575V AC |
Shipping Info:
| Ship weight (kg) | 15.75 |
| Ship height (cm) | 42.7 |
| Ship length (cm) | 40.8 |
| Ship width (cm) | 9.65 |
| Country of Origin | MX |
Product Variants
| Product | Model | Service Factor | Voltage | Phase | Hp | Frequency | Full Load Amps | Motor Type | Thermal Protection | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
137420 | 1.3 | 230V AC | 1 | 1 1/2 hp | 60 Hz | 10.6A | Split Phase | Automatic | €1,124.52 | |
|
137434 | 1.3 | 230V AC | 1 | 1 1/2 hp | 60 Hz | 10A | Split Phase | Manual | €920.40 | |
|
137418 | 1.4 | 230V AC | 1 | 1 hp | 60 Hz | 8.2A | Split Phase | Automatic | €859.97 | |
|
137432 | 1.4 | 230V AC | 1 | 1 hp | 60 Hz | 8.2A | Split Phase | Automatic | €744.71 | |
 |
137412 | 1.6 | 115V AC | 1 | 1/2 hp | 60 Hz | 10A | Split Phase | Automatic | €679.52 | |
 |
137426 | 1.6 | 115V AC | 1 | 1/2 hp | 60 Hz | 10A | Split Phase | Automatic | €626.62 | |
 |
137428 | 1.6 | 230V AC | 1 | 1/2 hp | 60 Hz | 5A | Split Phase | Automatic | €574.31 |
