LEESON 5KH37GNA782X 5KH37GNA782MX / HG717 Fan and Blower Motor, 0.33 HP, 1 Phase, 60 Hz, 115V, 1800 RPM
Get it by Tuesday, Aug 25
€101.14 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | HVAC Motor |
| Ambient (c) | 40°C |
| Ambient Temp. | 40°C |
| Duty Cycle | Continuous |
| Enclosure Type | Dripproof |
| Frame | 48Y |
| Frequency | 60 Hz |
| Full Load Amps | 6.2A |
| Hp | 1/3 hp |
| Insulation Class | Class B |
| Max. Ambient Temp. | 40°C |
| Motor Enclosure Design | Dripproof |
| Motor Mounting Position | All Angle |
| Motor Mounting Type | Resillient Ring |
| Motor Service Factor | 1 |
| Motor Shaft Rotation | CCW |
| Motor Thermal Protection | Automatic |
| Motor Type | Split Phase |
| Nameplate Speed | 1725 RPM |
| No. Of Speed | 1 |
| Phase | 1 |
| Service Factor | 1 |
| Shaft Dia. | 1/2" |
| Shaft Length | 13/25" |
| Shaft Orientation | Horizontal/Vertical |
| Thermal Protection | Automatic |
| Voltage | 115V AC |
Shipping Info:
| Ship weight (kg) | 6.3 |
| Ship height (cm) | 19.05 |
| Ship length (cm) | 32.08 |
| Ship width (cm) | 17.63 |
| HS code | 8501404040 |
| Country of Origin | MX |
Product Details:
- Starting Type: Switch and Mech
- KVA Code: T
- Drive End Bearing: BALL
- Opposite End Bearing: BALL
- Drive End Bearing Size: .500
- Opposite End Bearing Size: .500
