LEESON 131544.00 C184C17DC5A General Purpose Motor, 3 HP, 1 Phase, 60 Hz, 115/230V, 1800 RPM
Get it by Friday, Dec 19
€872.20 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Single Phase Motor |
| Ambient Temp. | 40°C |
| Code | J |
| Conduit Box Position | F1 |
| Drive End Bearing Size | 6206 |
| Drive End Bearing Type | Ball |
| Duty Cycle | Continuous |
| Efficiency | 75.5% |
| Enclosure Type | ODP |
| Frame | 184TC |
| Frame Material | Rolled Steel |
| Frame Type | 184TC |
| Frequency | 60 Hz |
| Full Load Amps | 33.8/16.9A |
| Grease Type | Polyrex EM |
| Hp | 3 hp |
| Insulation Class | Class F |
| Kw | 2.2 kW |
| Lubrication | Polyrex EM |
| Motor Enclosure Design | Dripproof |
| Motor Shaft Rotation | Selective Counter Clockwise |
| Motor Type | Capacitor Start/Run |
| Mounting Type | C Face, Footless |
| Nameplate Rpm | 1800 RPM |
| Nema Design | J, L |
| No. Of Poles | 4 |
| Opp. Drive End Bearing Size | 6205 |
| Opp. Drive End Bearing Type | Ball |
| Output Kw | 2.24 kW |
| Packaging | B |
| Phase | 1 |
| Power Factor | 76 |
| Rpm | 1700-1800 RPM |
| Service Factor | 1.15 |
| Shaft Dia. | 1 1/8" |
| Shaft Length | 2 3/4" |
| Type | CD |
| Voltage | 115-230V |
Shipping Info:
| Ship weight (kg) | 34.2 |
| Ship height (cm) | 32.72 |
| Ship length (cm) | 45.57 |
| Ship width (cm) | 33.17 |
| Country of Origin | MX |
Product Details:
- Eff 100%: 75.5
- Bearing OPE: 6205
- CC Number: EXEMPT
- Bearing PE: 6206
- Nameplate: 004003
- Winding: C8428
- GROUP: 3
- Paint: BLUE - LEESON (ENAMEL)
- S. F Amps: 37.8 / 18.9
Product Variants
| Product | Model | Motor Enclosure Design | Voltage | Nameplate Rpm | Hp | Full Load Amps | Mounting Type | Service Factor | Frame | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
131539.00 | Dripproof | 208-230V | 1800 RPM | 5 hp | 21-23A | C Face, Footless | 1.15 | 184TC | €1,224.50 | |
 |
131777.00 | Dripproof | 208-230V | 3600 RPM | 5 hp | 22.2-23A | C Face, Footless | 1.15 | 184TC | €1,151.78 | |
 |
E100025.00 | Open Dripproof | 115/230V AC | 1725 RPM | 1/2 hp | 4.6/2.3A | Round, C Face Footless | 1.25 | 56C | €802.83 |
