KECKLEY BVM3THRSSRGSL-150 Ball Valve, 1 1/2 Inch Pipe, 1920 PSI CWP, -50-500 Deg F
Item: CR6HTHModel: BVM3THRSSRGSL-150Cross Ref: 52RV40
7 In Stock
Ships within 2 days via
€503.84 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Ball Valve |
| 3-a Certified | Not Rated |
| Agency Compliance | Not Rated |
| Ansi Flange Class | Not Applicable |
| Average Surface Roughness | Not Applicable |
| Ball Material | Stainless Steel |
| Ball Material Grade | Grade 316 |
| Ball Opening Size | 1 1/4" |
| Ball Port Style | Standard Port |
| Ball Valve Product Group | Manual |
| Body Material | Stainless Steel |
| Body Seal Material | Graphite |
| Body Style | Inline |
| Coefficient Of Volume(cv) | 85 |
| Connection Gender Side 2 | Female |
| Connection Gender-side 1 | Female |
| Connection Size-side 1 | 1 1/2" |
| Connection Size-side 2 | 1 1/2" |
| Connection Type | FNPT x FNPT |
| Connection Type-side 1 | NPT |
| Connection Type-side 2 | NPT |
| For Media | Combustible Gases |
| Handle | Locking Lever |
| Handle Color | Red |
| Handle Height | 3.7" |
| Handle Length | 7 1/2" |
| Handle Material | Stainless Steel |
| Handle Material Grade | Grade 300 |
| Handle Type | Locking Lever |
| Handle-locking | Locking |
| Included Mounting | Iso 5211 Actuator Mounting Pad |
| Max. Pressure | 1920 psi |
| Max. Pressure (cwp) | 1920 psi |
| Max. Pressure For Combustible Gas | Not Rated |
| Max. Pressure-steam | 250 psi |
| Max. Steam Pressure | 250 psi WSP |
| Media Temp. | -50°F to +500°F |
| Nominal Valve Size | 1 1/2" |
| Overall Length | 4.5" |
| Pipe Schedule Compatibility | Not Applicable |
| Port | Standard |
| Seal Material | Graphite |
| Seat Material | RPTFE |
| Stem Grade | Grade 316 |
| Stem Material | Stainless Steel |
| Stem Type | Blowout Resistant |
| Temp. | -50°F to +500°F |
| Vacuum Service Rating | -29.912 in. hg |
| Valve Body Style | Straight |
| Valve Construction | Three-Piece |
| Valve Series | BVM3 Series |
| Valve Structure | Three Piece |
| Vented Ball Valve | Non Vented |
Shipping Info:
| Ship weight (kg) | 3.2 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 2.54 |
| Ship width (cm) | 2.54 |
Product Variants
| Product | Model | Body Material | Connection Type | Max. Pressure | Seat Material | Overall Length | Max. Steam Pressure | Coefficient Of Volume | Port | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
BVM3THFSSRGSL-150 | Stainless Steel | FNPT x FNPT | 1920 psi | RPTFE | 4.8" | 250 psi WSP | - | Full | €682.80 | |
|
BVM3SWFSSRGSL-150 | Stainless Steel | Socket x Socket | 1920 psi | RPTFE | 4.8" | 250 psi WSP | - | Full | €662.61 | |
|
BVM3SWRSSRGSL-150 | Stainless Steel | Socket x Socket | 1920 psi | RPTFE | 4.5" | 250 psi WSP | - | Standard | €507.27 | |
 |
BVM3THFCSRGSL-150 | Carbon Steel | FNPT x FNPT | 1973 psi | RPTFE | 4.8" | 250 psi WSP | - | Full | €476.53 | |
|
BVM3THRCSRGSL-150 | Carbon Steel | FNPT x FNPT | 1973 psi | RPTFE | 4.5" | 250 psi WSP | - | Standard | €325.54 | |
|
BVM3SWRCSRGSL-150 | Carbon Steel | Socket x Socket | 1973 psi | RPTFE | 4.5" | - | - | Standard | €311.99 | |
 |
BVS2THFSSRGSL-150 | Stainless Steel | FNPT x FNPT | 2160 psi | RPTFE | 4.3" | 200 psi WSP | - | Full | €247.16 |
