INGERSOLL-RAND SS3 Bare Air Compressor Pump, 1 Stage, Stainless Steel, 1200 RPM
Get it by Tuesday, Jul 7
Payment
Delivery
Product Specifications:
| Item | Air Compressor Pump |
| Bore Dia. | 2 3/4" , 2.75" |
| Construction | Cast Iron |
| Cylinder Material | Cast Iron |
| Duty Cycle | Continuous |
| Features | Removable Cylinders |
| Flywheel Dia. | 12 1/2" |
| Flywheel Included | Yes |
| Free Air Cfm @ Max. Pressure | 10.3 CFM |
| Free Air Flow Rate @ Max. Pressure | 10.3 CFM @ 135 psi |
| Groove Section | A |
| Lubrication Required | Yes |
| Lubrication Type | Splash Lubricated |
| Max. Operating Pressure | 135 psi |
| Max. Output Power | 3 hp |
| Max. Pressure | 135 psi |
| Mounting Pattern | 13"W x 15" D |
| No. Of Cylinders | 2 |
| No. Of Grooves | 1 |
| No. Of Stages | 1 |
| Npt Outlet | 3/8" |
| Oil Capacity | 16.9 fl. oz. |
| Outlet Connection Type | NPT |
| Outlet Size | 0.37" |
| Overall Height | 15" |
| Overall Width | 13" |
| Pump Rpm | 1200 |
| Pump Speed | 1200 RPM |
| Rotation | CCW |
| Sheave Size @ 1725 Rpm | 4-13/64" |
| Sheave Size @ 1725 Rpm | 4 13/64" |
| Stroke Length | 2" |
| Valve Material | Stainless Steel |
| Valve Type | Finger |
Shipping Info:
| Ship weight (kg) | 24.26 |
| Ship height (cm) | 38.1 |
| Ship length (cm) | 30.48 |
| Ship width (cm) | 33.02 |
| HS code | 8414801615 |
| Country of Origin | US |
Product Details:
Ingersoll Rand SS3 bare air compressor pump is ideal for generating a steady and reliable compressed air source for powering pneumatic tools, machinery and equipment in various industrial and commercial applications. It is used in workshops, construction sites, manufacturing facilities and automotive garages.
Features:
- It features a valve made of stainless steel and a cylinder made of cast iron for corrosion resistance and withstanding pressure up to 135 psi.
- It converts power (using a diesel / gasoline engine or an electric motor) into potential energy stored in pressurised air.
- It includes a filter, pump and flywheel.
Standards and Approvals:
- OSHA
- UL
- CSA
- ASME
Frequently Asked Questions:
Q. What is the difference between 1 & 2-stage air compressors?
A. Single-stage air compressors produce less energy than dual-stage air compressors. This low energy output is typically sufficient to run hand tools, especially for a small time period.
Q. Can this Ingersoll Rand SS3 bare air compressor pump's cylinder be interchanged?
A. It features removable cylinders, allowing for easy maintenance.
Q. What type of lubrication is used in this Ingersoll Rand air compressor pump?
A. This Ingersoll Rand SS3 compressor pump utilises splash lubrication, providing a continuous lubricant supply to moving parts. This can be beneficial for maintaining consistent performance and reducing wear and tear.
Q. What is the free flow rate of this Ingersoll Rand air compressor pump?
A. It allows a free air flow rate of 135 psi at a maximum pressure of 10.3 cfm.
Q. What is the oil capacity of Ingersoll Rand SS3 bare air compressor pump?
A. It has an oil capacity of 16.9 fl oz.
Product Variants
| Product | Model | Max. Operating Pressure | Pump Speed | Overall Width | Free Air Cfm @ Max. Pressure | Outlet Size | Groove Section | Npt Outlet | Flywheel Dia. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
SS5 Bare | 135 psi | 1000 RPM | 15" | 16.3 CFM @ 135 psi | 1/2" | A | 1/2" | 14 1/2" | €993.12 | |
 |
TS5 Bare | 175 psi | 1500 RPM | 15" | 17 CFM | 1/2" | A | 1/2" | 14 1/2" | €2,741.62 | |
 |
2340 | 175 psi | 1575 RPM | 18.18" | 15 CFM | 1/2" | A | 1/2" | 13 1/2" | €1,967.64 | |
 |
2545 | 175 psi | 1050 RPM | 27.62" | 16/27/35 CFM | 3/4" | B | 3/4" | 17.562" | €4,272.62 | |
 |
7100 | 175 psi | 1100 RPM | 26 1/2" | 37/50 CFM | 1" | B | 1" | 17 1/2" | €6,144.33 | |
 |
2475 | 175 psi | 1600 RPM | 19.68" | 16.8/24 CFM | 1/2" | A | 1/2" | 13 1/2" | €2,845.25 |
