IFM DN4218 Dc Power Supply, 100 To 240 VAC, Single, 24 To 28 VDC, 300 W, 12.5 A
Item: CR4LKAModel: DN4218Cross Ref: 801T47
7 In Stock
Ships within 2 days via
10.00% off
€1,130.21 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | DC Power Supply |
| Case Material | Aluminum Alloy |
| Current - Output | 12A |
| Depth | 59 mm |
| Features | Additional Diagnostics By Measuring Current, Voltage And Mains Quality As Well As Counting Operating Hours, Installation Without Control Cabinet, Protection Of The Wiring Via Configurable Electronic Circuit Breakers |
| Frequency | 50/60 Hz |
| Height | 183 mm |
| Hold Up Time | 33/33 ms @ 100/230V AC |
| Housing Material | Aluminum |
| Input Frequency - Maximuim | 60 Hz |
| Input Frequency - Minimum | 50 Hz |
| Input Frequency - Nominal | 50/60 Hz |
| Input Voltage | 100-240V AC/110-300V DC |
| Ip Rating | IP65, IP67 |
| Maximum Efficiency @ 230v Ac | 95.7% |
| Mounting | Wall |
| No. Of Output Circuits | 4 |
| Nominal Output Voltage | 24/28V DC |
| Operating Temperature - Maximum | 131°F |
| Operating Temperature - Minimum | -13°F |
| Output Amps | 12.5A |
| Output Power - Peak | 600 W |
| Output Power - Rated | 300 W |
| Output Voltage | 24-28V DC |
| Output Voltage - Minimum | 24V DC |
| Overall Depth | 7.21" |
| Overall Height | 7.17" |
| Overall Width | 2 8/25" |
| Phase | Single |
| Power Rating | 300 W |
| Power Supply Style | Switching |
| Sio Mode | Yes |
| Status Indicator | Green LED |
| Style | Switching |
| Width | 182 mm |
Shipping Info:
| Ship weight (kg) | 1.52 |
| Ship height (cm) | 18.3 |
| Ship length (cm) | 5.9 |
| Ship width (cm) | 18.2 |
| Country of Origin | CZ |
