HUBBELL WIRING DEVICE-KELLEMS HBLS5100C9W Straight Blade Connector, 100A, 4 Poles
Item: CJ3NGXModel: HBLS5100C9WCross Ref: 60HJ64
7 In Stock
Ships within 2 days via
5.00% off
€4,561.39 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Straight Blade Connector |
| Amps | 100A |
| Cap Type | Spring Loaded Cap |
| Compatible With Series | Advantage Series |
| Connection Orientation | Straight |
| Contact Material | Brass |
| Features | Spring Loaded Disconnect Button |
| For Max. Cable Dia. | 1.94" |
| For Min. Cable Dia. | 1.06" |
| Grounding | Grounded |
| Grounding Style | IEC |
| Housing Color | Blue |
| Housing Material | PBT |
| Hp | 15 hp |
| Ip Rating | IP68, IP69K |
| Market | Industrial |
| Max. Operating Temp. | 75°C |
| Max. Wire Size | 1 AWG |
| Min. Operating Temp. | -40°C |
| Min. Wire Size | 6 AWG |
| Nema Enclosure Rating | NEMA 4X |
| No. Of Poles | 4 |
| No. Of Wires | 5 |
| Outside Dia. | 5.63" |
| Overall Length | 15.89" |
| Phase | 3 |
| Power Indicating Light | Yes |
| Product Datasheet | hubbell-wiring-device-kellems-hbls5100c9w.pdf |
| Resistance Properties | Corrosion Resistant, Impact Resistant, Watertight |
| Reverse Service | No |
| Shrouded | Yes |
| Switch Rated | Yes |
| Ul 94 Flammability Rating | V-0 |
| Voltage | 120/208V AC |
| Wire Connection Type | Screw Terminal |
Shipping Info:
| Ship weight (kg) | 2.88 |
| Ship height (cm) | 14.3 |
| Ship length (cm) | 40.36 |
| Ship width (cm) | 14.3 |
| Country of Origin | US |
Documentation:
Product Variants
| Product | Model | No. Of Poles | Amps | Phase | Voltage | Housing Material | Housing Color | Color | Cord Size | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
HBL5269EBK | 2 | 15A | 1 | - | - | - | Black | #18 AWG to #10 AWG | €48.91 | |
 |
HBL515CVO | 2 | 15A | 1 | 125V | - | - | Orange | 18 AWG to 12 AWG | €37.22 | |
 |
HBL5369EBK | 2 | 20A | 1 | - | - | - | Black | #18 AWG to #10 AWG | €63.86 | |
 |
515C | 2 | 15A | 1 | 125V AC | Nylon | Black | Black | 0.245" to 0.655" | €23.82 | |
 |
HBL5963VBK | 2 | 15A | 1 | 125V | - | - | Black | #18 AWG to #16 AWG | €19.80 | |
 |
HBL5963VY | 2 | 15A | 1 | - | - | - | Yellow | #18 AWG to #16 AWG | €19.80 | |
 |
HBLS5100C5W | 4 | 100A | 3 | 347/600V AC | PBT | Black | - | - | €5,200.12 |
