HUBBELL WIRING DEVICE-KELLEMS HBL6375S Watertight Locking Receptacle, 50, Non-NEMA, 2 Poles, 4 Wires, 1 Phase
Item: CE6TCNModel: HBL6375SCross Ref: 24Y054
7 In Stock
3
12500 W
Black
Ships within 2 days via
10.00% off
€340.71 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Watertight Locking Receptacle |
| Afci | No |
| Amps | 50A |
| Color | Black |
| Connection Orientation | Straight |
| Connectivity | Screw Terminals |
| Cover Type | No Cover |
| Current Rating | 50A |
| Dielectric Strength | Withstands 2,000V minimum |
| Flange Shape | Rectangular |
| Flange Type | Flanged |
| For Environment | Dry |
| For Location | Indoor |
| Height | 3 3/4" |
| Housing Color | Black |
| Housing Material | Steel, Zinc Plated |
| Ip Rating | IP67 |
| Length | 3.8 mm |
| Market | Industrial |
| Material | Steel |
| Maximum Operating Temperature | 75°C |
| Maximum Wire Size | 6 AWG |
| Minimum Operating Temperature | -40°C |
| Minimum Wire Size | 10 AWG |
| Mount Type | Flush |
| Mounting | Screw Mounting |
| Nema Enclosure Rating | NEMA 4X |
| Nema Receptacle Configuration | Non-NEMA |
| Number Of Gangs | 1 |
| Number Of Poles | 3 |
| Number Of Wires | 4 |
| Phase | 1 |
| Polarized | Yes |
| Product Datasheet | hubbell-wiring-device-kellems-hbl6375s.pdf |
| Resistance Properties | Heat Resistant |
| Shrouded | Yes |
| Ul 94 Flammability Rating | V-0 |
| Voltage Rating | 125/250V AC |
| Wattage | 12500 W |
| Width | 3.43" |
| Wire Connection Type | Screw Terminals |
| Wire Size | #10 AWG to #6 AWG |
| Wiring Style | Standard |
Shipping Info:
| Ship weight (kg) | 0.36 |
| Ship height (cm) | 9.53 |
| Ship length (cm) | 9.65 |
| Ship width (cm) | 8.71 |
| Country of Origin | US |
Documentation:
Product Variants
| Product | Model | Number Of Poles | Number Of Wires | Phase | Current Rating | Voltage Rating | Housing Color | Ip Rating | Shrouded | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
HBL4716 | 2 | 3 | 1 | 15A | 125V AC | Black | IP20 | No | €66.42 | |
 |
CS6375 | 3 | 4 | 1 | 50A | 125/250V AC | Silver | IP20 | No | €263.89 | |
 |
HBL22CM428 | 3 | 4 | 3 | 20/30A | 250V DC/600V AC | Silver | IP30 | No | €1,131.69 | |
 |
HBL2455 | 4 | 4 | 3 | 20A | 277/480V AC | White | IP20 | No | €79.83 | |
 |
HBL2465 | 4 | 4 | 3 | 20A | 347/600V AC | White | IP20 | No | €90.69 | |
 |
HBL2655 | 2 | 3 | 1 | 30A | 600V AC | White | IP20 | No | €115.18 | |
 |
HBL2755 | 4 | 4 | 3 | 30A | 120/208V AC | White | IP20 | No | €135.39 |
