HUB CITY 0220-00514 Bevel Gear Drive, 16 HP, 1 Inch I.D, 1 Inch O.D, Cast Iron
Get it by Tuesday, Sep 1
€1,347.62 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Bevel Gear Drive |
| Gear Drive Size | 11 |
| Gear Type | Spiral Bevel |
| Housing Height | 4 19/32" |
| Housing Length | 6 7/16" |
| Housing Material | Cast Iron |
| Housing Width | 5 23/32" |
| Input Dia. | 1" |
| Input Hp @ 1750 Rpm | 16 hp |
| Input Style | Shaft |
| No. Of Gear Reductions | 1 |
| Output Dia. | 1" |
| Output Shaft | Shaft |
| Output Shaft Direction | Left Or Right |
| Output Speed | 1750 RPM |
| Output Torque | 500 lbs.-in. to 1000 lbs.-in. |
| Product Line | Bevel Gear Drives |
| Product Type | Right Angle |
| Ratio | 1:1 |
| Service Factor | 1 |
| Style | C, F |
| Torque | 580 lbs.-in. |
Shipping Info:
| Ship weight (kg) | 9.45 |
| Ship height (cm) | 19.05 |
| Ship length (cm) | 33.66 |
| Ship width (cm) | 31.75 |
Product Variants
| Product | Model | Output Speed | Output Torque | Max. Input Hp | Input Hp @ 1750 Rpm | Torque | Output Shaft Direction | Style | Gear Type | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
0220-00505 | 1150 RPM | 500 lbs.-in. to 1000 lbs.-in. | 12 hp | 12 hp | 660 lbs.-in. | Left Or Right | C, F | Straight Bevel | €879.25 | |
 |
0220-00503 | 1150 RPM | 500 lbs.-in. to 1000 lbs.-in. | 12 hp | 12 hp | 660 lbs.-in. | Left Or Right | D, E | Straight Bevel | €879.25 | |
 |
0220-00501 | 1150 RPM | 500 lbs.-in. to 1000 lbs.-in. | 12 hp | 12 hp | 660 lbs.-in. | Double | A, B | Straight Bevel | €879.25 | |
 |
0220-00518 | 1190.5 RPM | 250 lbs.-in. to 500 lbs.-in. | 6 1/10 hp | 6 1/10 hp | 330 lbs.-in. | Double | A, B | Straight Bevel | €1,558.58 | |
 |
0220-00512 | 1750 RPM | 500 lbs.-in. to 1000 lbs.-in. | - | 16 hp | 580 lbs.-in. | Left Or Right | D, E | Spiral Bevel | €1,414.99 | |
 |
0220-00529 | 972.2 RPM | 250 lbs.-in. to 500 lbs.-in. | 5 2/5 hp | 5 2/5 hp | 350 lbs.-in. | Left Or Right | D, E | Straight Bevel | €1,146.11 | |
 |
0220-00541 | 972.2 RPM | 250 lbs.-in. to 500 lbs.-in. | 5 2/5 hp | 5 2/5 hp | 350 lbs.-in. | Double | A, B | Straight Bevel | €1,558.58 |
