HONEYWELL MN7510A2001 Electric Actuator, Direct Mount, Floating/On/Off, 88 Inch lbs. Torque, 24V AC/DC
Item: CJ2BLQModel: MN7510A2001Cross Ref: 278Y19
7 In Stock
Ships within 2 days via
10.00% off
€494.03 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Electric Actuator |
| Application | Damper |
| Contact Form | SPDT |
| Control Signal | Proportional |
| Depth | 2 1/2" |
| Electrical Connection Type | Screw Terminals |
| For Use With | Air Handlers, Air Units, Louvers, Ventilation Flaps |
| For Use With Building Automation Systems | Building Automation System Compatible |
| Height | 5 1/4" |
| Includes | Mounting Bracket, Screws, Shaft Adapter, Water-Tight Strain-Relief Cable Fittings |
| Input Voltage | 24V AC |
| Ip Rating | IP54 |
| Maximum Operating Temperature | 140°F |
| Minimum Operating Temperature | -5°F |
| Mounting Type | Direct Mount |
| Nema Rating | 2 |
| Number Of Auxiliary Switches | 0 |
| Output Signal | Not Applicable |
| Overall Depth | 2 1/2" |
| Overall Height | 5 1/4" |
| Overall Width | 2 1/2" |
| Power Consumption | 5 VA |
| Product Type | Actuator |
| Rated Torque | 88 lbs.-in. |
| Return Action | Non-Spring Return |
| Shaft Rotation | CW/CCW |
| Shaft Type | U Bolt Clamp |
| Signal Type | Proportional |
| Stroke Degree | 95° |
| System Application | Air Handlers, Air Units, Dampers, Louvers, Ventilation Flaps |
| Time To Close | 95 sec. |
| Time To Open | 90 sec. |
| Valve Application | Damper |
| Width | 2 1/2" |
Shipping Info:
| Ship weight (kg) | 0.68 |
| Ship height (cm) | 13.34 |
| Ship length (cm) | 6.35 |
| Ship width (cm) | 6.35 |
| Country of Origin | MX |
Product Variants
| Product | Model | Overall Height | Height | Price | |
|---|---|---|---|---|---|
 |
M7284A1004/U | 6 1/2" | 6.437" | €2,862.96 | |
 |
M7284C1000/U | 6 1/2" | 6.437" | €3,138.98 | |
 |
MN7505A2001 | 5 1/4" | 5 9/32" | €473.71 | |
 |
MN6105A1011 | 5 1/4" | - | €344.33 | |
 |
MS8120F1200 | 10 3/4" | 10 11/16" | €1,136.68 | |
 |
MS8105A1130 | 7 1/2" | - | €634.92 | |
|
MN7220A2205 | 8 3/4" | 8 25/32" | €1,029.60 |
