HONEYWELL LSF4L Heavy Duty Limit Switch Side Actuator
Item: AA4NBLModel: LSF4LCross Ref: 12V088
7 In Stock
Ships within 2 days via
10.00% off
€693.98 /unit
This product can only be shipped in multiples of 5Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Heavy Duty Limit Switch |
| Ac Contact Rating | 10A @ 600V |
| Action | Momentary |
| Actuator Length | 1.74" |
| Actuator Length - Limit Switch | 1.74" |
| Actuator Location | Side |
| Actuator Style | Roller Plunger |
| Actuator Style - Limit Switch | Plunger, Roller |
| Actuator Type | Roller plunger |
| Basic Actuator Style | Plunger |
| Basic Actuator Style (limit Switch) | Plunger |
| Body Configuration | Non Plug In |
| Body Construction | Die Cast Zinc |
| Body Depth | 1.79" |
| Body Height | 3.53" |
| Body Height - Limit Switch | 3.69" |
| Body Material | Zinc |
| Body Material Type | Metallic |
| Body Style | Standard |
| Body Style - Limit Switch | Standard |
| Body Width | 1 22/25" |
| Boot Sealed Actuator | No |
| Boot Sealed Actuator - Limit Switch | No |
| Contact Form | 2NO/2NC |
| Current Rating - Nominal | 10A |
| Dc Contact Rating | 10A @ 250V |
| Depth | 1.79" |
| Differential Travel | 0.04" |
| Differential Travel Length | 0.045" |
| Display Qty | 1 |
| Electrical Connection | Screw Terminals |
| Head Action | Spring Return, Standard |
| Height | 4.69" |
| Ip Rating | IP65, IP66, IP67 |
| Limit Switch Style | Heavy Duty Limit Switch |
| Maximum Operating Force | 26.7N |
| Mounting - Limit Switch | Surface |
| Mounting Hole Diameter - New | 1/5" |
| Mounting Hole Horizontal Center To Center Distance | 60 mm |
| Mounting Hole Spacing - Limit Switch | 2.34" x 1.16" |
| Mounting Hole Vertical Center To Center Distance | 30 mm |
| Mounting Style | Surface |
| Movement | Cam, Slide |
| Nema Enclosure Rating | NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13 |
| Nema Rating | NEMA 1, NEMA 3, NEMA 4, NEMA 4X, NEMA 6, NEMA 6P, NEMA 12, NEMA 13 |
| Number Of Mounting Holes | 2 |
| Operating Force | 6 lbs.-in. |
| Operating Temp. Range | +10°F to +200°F |
| Operating Temperature - Maximum | 250°F |
| Operating Temperature - Minimum | 10°F |
| Over Travel Length | 0.19" |
| Overall Depth | 2.44" |
| Overall Height | 4.69" |
| Overall Width | 1 22/25" |
| Overtravel - New | 0.19" |
| Pre-travel Length | 0.07" |
| Pretravel | 0.1" |
| Resistance Properties | Corrosion Resistant |
| Roller Diameter | 1/2" |
| Roller Width | 0.19" |
| Series | HDLS Series |
| Stem Thread - Limit Switch | No Stem |
| Width | 1 22/25" |
Shipping Info:
| Ship weight (kg) | 0.89 |
| Ship height (cm) | 5.59 |
| Ship length (cm) | 15.24 |
| Ship width (cm) | 8.13 |
| HS code | 8536509055 |
| Country of Origin | US |
Product Variants
| Product | Model | Actuator Style | Contact Form | Operating Temp. Range | Body Material | Body Width | Boot Sealed Actuator | Body Height | Body Style | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
LSV7L | Plunger | 2NO/2NC | +10°F to +200°F | Metal | 1 22/25" | No | 2.95" | Miniature | €517.54 | |
 |
LSW1A | Plunger | 1NO/1NC | +10°F to +200°F | Metal | 1.62" | No | 3.2" | Standard | €520.40 | |
 |
LSYPB1A | No Lever, Rotary Head | - | -40°F to +250°F | Die Cast Zinc | 1.62" | No | - | Standard | €394.52 | |
|
LSYUB1A | No Lever, Rotary Head | 1NO/1NC | -40°F to +250°F | Metal | 1.62" | No | 3.2" | X | €460.78 | |
|
LSA1A | No Lever, Rotary Head | 1NO/1NC | +10°F to +250°F | Zinc | 1.62" | No Boot Included | 2.95" | X | €369.89 | |
 |
LSA2B | No Lever, Rotary Head | 2NO/2NC | +10°F to +250°F | Zinc | 1.88" | No | 3.53" | X | €369.77 | |
|
LSA3K | No Lever, Rotary Head | 1NO/1NC | +10°F to +250°F | Zinc | 1.62" | No Boot Included | 2.95" | X | €292.78 |
