HARRINGTON NER005LD-FG-10 Electric Chain Hoist 1000lb 10 feet 15/2.5fpm
Get it by Friday, Dec 19
10.00% off
€11,870.23 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Electric Chain Hoist |
| Amperage Draw | 3.4A |
| Amps @ Low Volts | 3.4A |
| Body Depth | 14 5/8" |
| Body Finish | Epoxy Painted |
| Body Length | 22 3/8" |
| Body Width | 8 1/2" |
| Brake Type | DC Current |
| Capacity | 1000 lbs. |
| Chain Finish | Epoxy Painted |
| Classification | H4 |
| Clutch | Friction |
| Clutch Type | Friction |
| Color | White |
| Configuration | Hook Mounted - No Trolley |
| Control | Push Button Pendant |
| Controller Cord Length | 6 ft. |
| Duty Classification | H4 - Heavy Duty |
| Finish | Epoxy Paint |
| Fits Brand | Harrington Hoists Inc |
| Fixed Lift Speed | Not Applicable |
| For Max. Beam Height | Not Applicable |
| For Maximum Beam Flange Width | Not Applicable |
| For Minimum Beam Flange Width | Not Applicable |
| For Minimum Beam Height | Not Applicable |
| Headroom | 14 5/8" |
| Headroom Size | 14 5/8" |
| Housing Depth | 14 5/8" |
| Housing Length | 22 3/8" |
| Housing Width | 8 1/2" |
| Includes | Chain Container, Pendant, Quick Disconnect Plugs On Pendant, Safety Latch Hook |
| Includes Brake | Brake Included |
| Includes Clutch | Clutch Included |
| Lift | 10 ft. |
| Lift Speed | 2.5-15 FPM |
| Lifting Capacity | 1000 lbs. |
| Lifting Hook Material | Carbon Steel |
| Lifting Hook Opening Width | 14 5/8" |
| Lifting Hook Type | Swivel Hook With Safety Latch |
| Load Capacity | 1000 lbs. |
| Lubrication | Food Grade Oil |
| Manufacturers Warranty Length | 1 yr. |
| Max Current Draw | 3.4A |
| Maximum Lift Speed | 15 FPM |
| Maximum Lifting Length | 10 ft. |
| Maximum Pulling Capacity | Not Applicable |
| Min. Between Hooks | 14 5/8" |
| Min. Radius Curve | Not Applicable |
| Minimum Lift Speed | 2.5 FPM |
| Minimum Retracted Length | 14 19/32" |
| Motor Hp | 3/4 hp |
| Mount Type | Hook Mounted - No Trolley |
| Number Of Load Chains | 1 |
| Number Of Reeves | 1 |
| Number Of Speeds | 2 |
| Operating Voltage | 460V AC |
| Overload Protection Included | Yes |
| Pendant Ip Rating | IP65 |
| Phase | 3 |
| Reeving | 1 |
| Speed Programmability | Programmable By VFD |
| Thermal Protection | Included |
| Tonnage - Lifting Capacity | 0.5 ton. |
| Trolley Wheel Dia. | Not Applicable |
| Trolley Wheel Material | Not Applicable |
Shipping Info:
| Ship weight (kg) | 31.95 |
| Ship height (cm) | 45.72 |
| Ship length (cm) | 12.7 |
| Ship width (cm) | 43.18 |
| HS code | 8425110000 |
Product Variants
| Model | Lifting Capacity | Motor Hp | Lift Speed | Lifting Hook Opening Width | Max Current Draw | Minimum Retracted Length | Speed Programmability | Operating Voltage | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| NER003L-FG-10 | 500 lbs. | 3/4 hp | 15 FPM | 13 13/16" | 3.4A | 14 19/32" | Non Programmable | 230/460V AC | €11,509.50 | |
| NER005L-FG-10 | 1000 lbs. | 3/4 hp | 15 FPM | 14 5/8" | 3.4A | 14.594" | Non Programmable | 230/460V AC | €11,299.16 | |
| NER010L-FG-10 | 2000 lbs. | 1 1/4 hp | 14 FPM | 17" | 4.8A | 16.906" | Non Programmable | 230/460V AC | €12,401.72 | |
| NER020L-FG-10 | 4000 lbs. | 2 3/8 hp | 14 FPM | 22 5/8" | 2.4A | 22 19/32" | Non Programmable | 230/460V AC | €15,630.41 | |
| NER003LD-FG-10 | 500 lbs. | 3/4 hp | 2.5-15 FPM | 13 13/16" | 3.4A | 14 19/32" | Programmable By VFD | 460V AC | €13,206.70 | |
| NER010LD-FG-10 | 2000 lbs. | 1 1/4 hp | 2.5-14 FPM | 17" | 4.8A | 16 29/32" | Programmable By VFD | 460V AC | €14,545.52 | |
| NER020LD-FG-10 | 4000 lbs. | 2 3/8 hp | 2.5-14 FPM | 22 5/8" | 2.4A | 22 19/32" | Programmable By VFD | 460V AC | €17,979.23 |
