HUBBELL - BRYANT 70520IG Flush Receptacle, 20A, 2-Pole, 3-Wire Grounding, Screw Terminal, Black
Get it by Monday, Aug 24
€19.89 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Receptacle |
| Amps | 20A |
| Application | Extra Heavy Duty Industrial Specification Grade |
| Connectivity | Terminal Screws |
| Dimensions | 3.28" x 1.7" x 1.24" |
| Display Size | Standard Size |
| Environmental Conditions | Indoor Dry Unless Protected By Additional Means |
| Height | 1 6/25" |
| Length | 3 7/25" |
| Material | Composite |
| Mounting Hardware | Screw Mounting |
| No. Of Poles | 2 |
| No. Of Wires | 3 |
| Phase | 1 |
| Product Datasheet | hubbell-bryant-70520ig.pdf |
| Series | Locking |
| Style | Isolated Ground |
| Type | Single Receptacle |
| Voltage | 125V |
| Width | 1.7" |
| Wire Size | #14 AWG to #8 AWG |
Shipping Info:
| Ship weight (kg) | 0.54 |
| Ship height (cm) | 3.15 |
| Ship length (cm) | 8.33 |
| Ship width (cm) | 4.32 |
Documentation:
