GREENLEE HPB45-1AVS Paving Breaker, 1-1/8 Inch Shank Diameter, 6 Inch Shank Length
Get it by Tuesday, Sep 1
5.00% off
€6,864.25 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Paving Breaker |
| Application | For Breaking Sidewalks And Curbs Or Driving Ground Rod, And For Other Small Demolition Jobs |
| Blow Energy | 63 lbs.-ft. |
| Blows Per Minute | 2160 BPM |
| Flow Rate | 8 GPM |
| Handle Type | Cushioned/Spring Dampened |
| Height | 28 1/2" |
| Hydraulic System Type | Open Center |
| Impact Energy | 63 ft.lb., 85 Joules |
| Included | 1/2" Bsp To 1/2" Nptf Adaptors, Whip Hoses |
| Length | 28 1/2" |
| Max. Back Pressure | 400 psi , 405 psi |
| Max. Back Pressure | 400 psi |
| Max. Blows Per Minute | 2160 BPM |
| Max. Flow Rate | 8 GPM |
| Max. Oil Temp. | 140 Degrees F |
| Max. Oil Temp. | 140°F , 158°F |
| Max. Operating Pressure | 1800 psi |
| Max. Pressure | 2300 psi |
| Min. Flow (gpm) | 5 |
| Min. Flow Rate | 5 GPM |
| Min. Oil Temp. | 86°F |
| Min. Operating Pressure | 105 psi |
| No. Of Chisels Included | 2 |
| Piston Stroke Length | 6" |
| Pressure Port | 1/2" NPTF Female |
| Product Type | Paving Breaker |
| Recommended Filtration | 10 µm |
| Recommended Filtration (microns) | 10 |
| Relief Valve Pressure Setting | 2300 psi |
| Retainer Type | Latch |
| Return Port | 1/2" NPTF Female |
| Shank Dia. | 1 1/8" |
| Shank Length | 6" |
| Shank Shape | Hex |
| Shank Size | 1.125" x 6" |
| Sound Level | 110 dBA |
| Sound Level Db | 110 dB |
| Sound Power Level | 110 dB |
| Tool Height | 28 1/2" |
| Tool Length | 28 1/2" |
| Tool Series | HPB45 Series |
| Tool Weight | 54 lbs. |
| Tool Width | 6" |
| Type | Hydraulic |
| Vibration Level | 11.4 m/sq. sec., 5.3 m/sq. sec. |
| Width | 6" |
Shipping Info:
| Ship weight (kg) | 26.1 |
| Ship height (cm) | 13.97 |
| Ship length (cm) | 76.71 |
| Ship width (cm) | 46.99 |
| HS code | 8479899899 |
| Country of Origin | BG |
Product Details:
- Used for demolishing concrete structures, sidewalks and similar constructions
- Compact modular design with few protrusions to provide comfort to users
- Equipped with internal rubber damper to reduce chisel noise
- Maximum breaking power owing to high blow energy
Frequently Asked Questions:
Q. What accessories are available for GREENLEE paving breaker?
A. F020196K HTMA Female Coupler having 1/2 inch NPTF internal thread and F020197K HTMA Male Coupler having 1/2 inch NPTF internal thread are compatible with this paving breaker.
Q. What is pavement breaker used for?
A. Pavement breaker is designed for various demolition jobs, such as breaking concrete, pavements & roads.
