GRAINGER RFSL2-580-2.5-5 Rivet Nut, M5x0.8 Thread Size, Steel, 10.3 mm Lg., 0.5 In To 2.5 In Grip Rng, Open
Item: AG2TXWModel: RFSL2-580-2.5-5Cross Ref: 32FX24
7 In Stock
Ships within 2 days via
10.00% off
€9.10 /pkg. of 5
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Rivet Nut |
| Body Dia. | 10.95 mm |
| Body Length | 10.3 mm |
| Body Texture | Knurled |
| Body Type | Round |
| Compatible Material | Metal |
| Display Qty | 5 |
| Drill Bit Size | 11 mm |
| Drill Size | 7/16" |
| End Type | Open |
| Flange Dia. | 14.1 mm |
| Flange Style | Flanged |
| Flange Thickness | 0.85 mm |
| Grip Range | 0.5" to 2.5" |
| Head Height | 0.85 mm |
| Insert Diameter | 14.1 mm |
| Insert Nut Type | Rivet Nut |
| Installed Length | 6.25 mm |
| Length | 10.3 mm |
| Material | Steel |
| Material Grade/class | Grade 1008, Grade 1010 |
| Maximum Hole Diameter | 11 mm |
| Maximum Material Thickness | 2.5 mm |
| Minimum Material Thickness | 0.5 mm |
| Nut Type | Floating Thread |
| Overall Length | 11.2 mm |
| Rivet Type | Floating Thread |
| System Of Measurement | Metric |
| Thread Fit | 2B |
| Thread Size | M5 x 0.8 |
| Thread Type | Coarse |
Shipping Info:
| Ship weight (kg) | 2.25 |
| Ship height (cm) | 12.7 |
| Ship length (cm) | 35.56 |
| Ship width (cm) | 27.94 |
| HS code | 7318190000 |
Product Variants
| Product | Model | Thread Size | Rivet Type | Flange Dia. | Finish | Drill Size | Head Height | Grade | Pkg. Qty. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
U69136.019.0080 | #10-24 | Flanged | 13/32" | Plain | 1/4" | 0.038" | - | 100 | €22.58 | |
 |
U69136.037.0200 | 3/8"-16 | Flanged | 0.78125" | Plain | 1/2" | 0.088" | - | 20 | €16.92 | |
 |
U69136.031.0125 | 5/16"-18 | Flanged | 0.665" | Plain | Z | 1/16" | - | 25 | €16.46 | |
 |
U69136.037.0115 | 3/8"-16 | Flanged | 0.78125" | Plain | 1/2" | 0.088" | - | 25 | €20.29 | |
 |
U69136.025.0138 | 1/4"-20 | Flanged | 0.475" | Plain | Q | 0.06" | - | 40 | €21.47 | |
 |
U69136.025.0200 | 1/4"-20 | Flanged | 0.475" | Plain | Q | 0.058" | - | 40 | €24.61 | |
 |
U69136.016.0120 | #8-32 | Flanged | 0.357" | Plain | #2 | 0.032" | - | 50 | €37.48 |
