GORILLA MILL GMKD12CH4 50055 Carbide End Mill, 3 Inch Length, 4 Flute, Weldon Flat, Chamfer End
Item: AG6NVGModel: GMKD12CH4Cross Ref: 36PR27 / 50055
7 In Stock
0.5"
4
1"
Ships within 2 days via
€171.87 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Carbide End Mill |
| Chamfer Angle | 45° |
| Coating | GMS2 |
| Cut Dia. Tolerance | -0.002" to 0" |
| Cutting Direction | Right Hand |
| Cutting Length | 1" |
| D1 Cutting Dia. | 0.5" |
| D2 Shank Dia. | 0.5" |
| Dimensions Type | Fractional Inch |
| Drilling Tool Configuration | Individual |
| End Mill Application | Roughing |
| End Mill Cutting Type | Non Center Cutting |
| End Mill Style | Corner Chamfer |
| End/corner Shape | Chamfer |
| Finish-machining | GMS |
| Grade | Grade C2 |
| Length Of Cut Tolerance | 0.025" to 0.05" |
| List Number | GMKD12CH4 |
| Machining Methods | Profiling, Full Slotting, Pocketing, High-velocity |
| Material | Carbide |
| Material Grade-machining | Grade C2 Micro Grain |
| Material-machining | Carbide |
| Measurement System | Fractional Inch |
| Milling Dia. | 1/2" |
| No. Of Flutes | 4 |
| Overall Length | 3" |
| Overall Length Tolerance | -0.05" to +0.05" |
| Performance | High Performance |
| Primary Material Application | Nickel, Stainless Steel, Steel, Titanium, Tool And Die Steel |
| Primary Material Application Iso Code | M, P, S |
| Shank Dia. | 1/2" |
| Shank Dia. Tolerance | -0.0001" to -0.0005" |
| Shank Type-machining | Weldon Flat |
| Single End/double End | Single End |
| Tool Length | Standard |
| Tool Type | Carbide End Mill Rougher |
Shipping Info:
| Ship weight (kg) | 0.27 |
| Ship height (cm) | 2.54 |
| Ship length (cm) | 7.62 |
| Ship width (cm) | 2.54 |
| HS code | 8207701000 |
| Country of Origin | US |
Product Details:
- Single End/Double End (Single End)
