ENERPAC rc1003a 100 Ton CH SA 3 Stroke Cyl
€7,038.38 /unit
Request a Quote
Payment
Delivery
Product Specifications:
| Base To Port Center Line E | 1 1/2" |
| Body Outside Dia. C | 8.38" |
| Capacity | 100 ton. |
| Center Hole Dia. F | 3.11" |
| Collapsed Height A | 10" |
| Collar Threads G In | 8 3/8" to 12" |
| Collar Threads Length G | 2.38" |
| Cylinder Effective Area | 20.6 sq. in. |
| Cylinder Effective Area In | 20 3/5" |
| Extended Height B | 13" |
| Material | Steel |
| Max. Operating Pressure | 10000 psi |
| Oil Capacity Required | 62 cu. in. |
| Oil Capacity Required (cm3) | 1016 cu. cm |
| Oil Capacity Required In | 62" |
| Piston Outside Dia. D | 5" |
| Plunger Type | Center Hole |
| Pressure @ Capacity | 9694 psi |
| Return Type | Single Acting, Spring Return |
| Stroke | 3" |
| Thread | 5/8" To 11" UNC |
| Thread Depth | 3/4" |
| Thread Size | 5/8"-11 |
| Thread Type | UNC |
