ENERPAC r756 75 Ton Spr Ret SA 6 Stroke Cyl
€4,052.74 /unit
Request a Quote
Payment
Delivery
Product Specifications:
| Base To Port Center Line E | 1.19" |
| Body Outside Dia. C | 5 3/4" |
| Capacity | 75 ton. |
| Collapsed Height A | 11.31" |
| Collar Threads G In | 5 3/4" to 12" |
| Collar Threads Length G | 1 3/4" |
| Cylinder Effective Area | 15.9 sq. in. |
| Cylinder Effective Area In | 15.9" |
| Extended Height B | 17.37" |
| Material | Steel |
| Max. Operating Pressure | 10000 psi |
| Oil Capacity Required | 95.4 cu. in. |
| Oil Capacity Required (cm3) | 1563 cu. cm |
| Oil Capacity Required In | 95 2/5" |
| Piston Outside Dia. D | 3 3/4" |
| Plunger Type | Solid |
| Pressure @ Capacity | 9430 psi |
| Ram Bore Dia. | 114 mm , 4 1/2" |
| Return Type | Single Acting, Spring Return |
| Stroke | 6.06" |
