ENERPAC r251 25 Ton Spr Ret SA 1 Stroke Cyl
€753.44 /unit
Request a Quote
Payment
Delivery
Product Specifications:
| Body Outside Dia. C | 3.37" |
| Capacity | 25 ton. |
| Collapsed Height A | 5 1/2" |
| Collar Threads G In | 2 3/4" to 16" |
| Collar Threads Length G | 1.19" |
| Cylinder Effective Area | 5.16 sq. in. |
| Extended Height B | 6 1/2" |
| Material | Steel |
| Max. Operating Pressure | 10000 psi |
| Oil Capacity Required | 5.16 cu. in. |
| Oil Capacity Required (cm3) | 84 cu. cm |
| Piston Internal Dia. Threads F | 1 1/2"-16 |
| Piston Outside Dia. D | 2 1/4" |
| Piston Thread Depth F | 1.13" |
| Plunger Type | Solid |
| Pressure @ Capacity | 9690 psi |
| Ram Bore Dia. | 2 14/25" , 65 mm |
| Return Type | Single Acting, Spring Return |
| Stroke | 1" |
| Thread | 0.5" To 13" UNC |
| Thread Depth | 3/4" |
| Thread Size | 1/2"-13 |
| Thread Type | UNC |
