ELOBAU 122261 Safety Sensor, Magnetically Actuated, N.O./N.O./N.O., 1m Cable
Get it by Tuesday, Dec 23
€78.43 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Sensor |
| Actuation Type | Front |
| Assured Switch Off Distance | 25 mm |
| Assured Switching Distance | 15 mm |
| Cable Length | 1m |
| Communication Method | Hard Wired |
| Housing Color | Black |
| Housing Design | Cylindrical |
| Housing Material | PBT |
| Ip Rating | IP67 |
| Led Display | No |
| Length | 46 mm |
| Max. Operating Temp. | 75°C |
| Max. Operating Temp. | 75 Deg. C |
| Max. Switching Current | 0.1A |
| Max. Switching Voltage | 28.8V DC |
| Min. Switching Distance | 0.5 mm |
| Min. Switching Voltage | 19.2V DC |
| Mounting Type | Fastening Nut |
| Operating Voltage | 19.2-28.8V DC |
| Sensing Technology | Reed |
| Series Resistor | 22 ohms |
| Switching Frequency | 5 Hz |
| Switching Principle | Magnetic |
| Technology | Reed |
| Thread Size | M12 |
Shipping Info:
| Ship weight (kg) | 0.03 |
| Country of Origin | DE |
Product Variants
| Product | Model | Ip Rating | Housing Material | Cable Length | Mounting Type | Led Display | Max. Operating Temp. | Housing Color | Min. Operating Temp. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
![]() |
153210 | - | Nylon | 1m | Screw | - | 70°C | - | -25°C | €36.91 | |
![]() |
171V62AY | - | PBT | - | Fastening Nut | No | 75°C | Silver | -25°C | €98.40 | |
![]() |
114270A0D | - | - | - | Screwed | No | - | - | - | €97.66 | |
![]() |
171V62VY | IP67, IP69K | Stainless Steel | - | Fastening Nut | No | 75°C | Silver | -25°C | - | RFQ
|
![]() |
114270-5 | IP67 | - | 1m | Screw | No | 75°C | Black | -25°C | €116.86 | |
![]() |
153V62-10 | - | - | - | - | - | - | - | - | €141.86 | |
![]() |
165270-5 | IP67 | - | 1m | Screwed | No | 75°C | Black | -25°C to +75°C | €98.45 |
