EATON XTPE1P2BCS Manual Motor Protector, Non-Reversing, 3 Poles, 1.2 A, Electronic Protection
Item: CJ2UFQModel: XTPE1P2BCSCross Ref: 5PZZ8
7 In Stock
Ships within 2 days via
5.00% off
€788.80 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Manual Motor Protector |
| Amps | 1.2A |
| Depth | 4 18/25" |
| Features | Phase Loss Sensitivity |
| Frame Size | B |
| Height | 3.98" |
| Hp @ 3 Phase-480v | 1/2 hp |
| Hp @ 3 Phase-575v | 1/2 hp |
| Hp @ 3 Phase-600v | 1/2 hp |
| Included Pilot Light | No |
| Max. Overload Relay Amps Setting | 1.2A |
| Max. Voltage | 600V AC |
| Min. Overload Relay Amps Setting | 0.3A |
| Mounting Style | DIN Rail |
| Nema Enclosure Rating | No Enclosure |
| Nema Size | Not Applicable |
| No. Of Poles | 3 |
| No. Of Required Thermals | Not Applicable |
| Operator | Selector Switch |
| Overall Depth | 4" |
| Overall Height | 4 1/4" |
| Overall Width | 2" |
| Overload Protection Type | Electronic |
| Phase | 3 |
| Phase Loss Sensitivity | Yes |
| Product Height | 4 1/4" |
| Product Length/depth | 4" |
| Product Width | 2" |
| Reversing Capability | Non Reversing |
| Series | XTPE Series |
| Starter Style | IEC |
| Starter Type | Manual |
| Terminal Connection Type | Screw Terminal |
| Thermal Units Required | None (Not Applicable to Electronic Overloads) |
| Trip Class | Class 5, Class 10, Class 15, Class 20 |
| Type | Assembly |
| Width | 1.77" |
| Wire Termination Type | Screws |
Shipping Info:
| Ship weight (kg) | 0.49 |
| Ship height (cm) | 10.8 |
| Ship length (cm) | 10.16 |
| Ship width (cm) | 5.08 |
| Country of Origin | DE |
Product Variants
| Product | Model | Frame Size | Amps | Overall Depth | Overall Height | Overall Width | Depth | Height | Type | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
XTPR001BC1 | B | 1A | 3" | 2" | 3" | 3.46" | 3.66" | Rotary | €407.05 | |
|
XTPR1P6BC1 | B | 1.6A | 1.93" | 3.74" | 3.66" | 3.46" | 3.66" | Motor Protector | €422.86 | |
 |
XTPE065DCS | D | 65A | 7 1/2" | 2 1/2" | 8 1/2" | 7 9/25" | 6.3" | Assembly | €1,044.89 | |
|
XTPR032BC1 | B | 32A | 3.7" | 3.66" | 1.77" | 3.46" | 3.66" | Rotary | €539.85 | |
 |
XTPBP40BC1 | B | 0.4A | 2" | 4" | 4" | 3.35" | 3.66" | Push Button | €361.54 | |
|
XTPB6P3BC1 | B | - | 4" | 2" | 4" | - | - | - | €412.25 | |
|
XTPB004BC1 | B | 4A | 4" | 2" | 3 1/2" | 3.35" | 3.66" | Push Button | €427.21 |
