EATON XTPE065DCS Manual Motor Protector, Non-Reversing, 3 Poles, 65A, Electronic Protection, Selector Switch
Item: CJ2UEXModel: XTPE065DCSCross Ref: 41N933
7 In Stock
Ships within 2 days via
10.00% off
€940.40 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Manual Motor Protector |
| Current Ac | 65A |
| Depth | 7 9/25" |
| Features | Phase Loss Sensitivity |
| Frame Size | D |
| Height | 6.3" |
| Horsepower @ Single Phase - 120v Ac | 3 hp |
| Horsepower @ Single Phase - 240v Ac | 7 1/2 hp |
| Horsepower @ Three Phase - 208v Ac | 15 hp |
| Horsepower @ Three Phase - 240v Ac | 15 hp |
| Horsepower @ Three Phase - 600v Ac | 40 hp |
| Hp @ 1 Phase - 115v | 3 hp |
| Hp @ 1 Phase - 230v | 7 1/2 hp |
| Hp @ 3 Phase - 200v | 15 hp |
| Hp @ 3 Phase - 240v | 15 hp |
| Hp @ 3 Phase - 460-575v | 40 hp |
| Hp @ 3 Phase - 480v | 40 hp |
| Hp @ 3 Phase - 575v | 40 hp |
| Includes Pilot Light | No |
| Maximum Overload Relay Current Setting | 65A |
| Maximum Voltage Rating | 600V AC |
| Min. Overload Relay Amps Setting | 16A |
| Mounting Style | DIN Rail |
| Nema Enclosure Rating | No Enclosure |
| Nema Size | Not Applicable |
| No. Of Required Thermals | Not Applicable |
| Number Of Poles | 3 |
| Operator | Selector Switch |
| Overall Depth | 7 1/2" |
| Overall Height | 2 1/2" |
| Overall Width | 8 1/2" |
| Overload Protection Type | Electronic |
| Phase | Three |
| Phase Loss Sensitivity | Yes |
| Product Height | 2 1/2" |
| Product Length/depth | 7 1/2" |
| Product Width | 8 1/2" |
| Reversing Capability | Non-reversing |
| Series | XTPE Series |
| Starter Style | IEC |
| Starter Type | Manual |
| Terminal Connection Type | Screw Terminals |
| Thermal Units Required | None (Not Applicable to Electronic Overloads) |
| Trip Class | Class 5, Class 10, Class 15, Class 20 |
| Type | Assembly |
| Width | 2.17" |
| Wire Termination Type | Screws |
Shipping Info:
| Ship weight (kg) | 1.58 |
| Ship height (cm) | 6.35 |
| Ship length (cm) | 19.05 |
| Ship width (cm) | 21.59 |
| Country of Origin | DE |
Product Variants
| Product | Model | Number Of Poles | Price | |
|---|---|---|---|---|
 |
XTPR001BC1 | 3 | €407.05 | |
|
XTPR1P6BC1 | 3 | €422.86 | |
|
XTPR032BC1 | 3 | €539.85 | |
 |
XTPBP40BC1 | 3 | €361.54 | |
|
XTPB6P3BC1 | 3 | €412.25 | |
|
XTPB004BC1 | 3 | €427.21 | |
 |
XTPR025DC1 | 3 | €742.10 |
