EATON XTCF200G00T IEC Magnetic Contactor, Non-Reversing, 4 Poles, 115 A, 24 VAC Coil, G Frame Size
Item: CJ2NVHModel: XTCF200G00TCross Ref: 21EP18
7 In Stock
Ships within 2 days via
10.00% off
€1,771.13 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | IEC Magnetic Contactor |
| Coil Voltage | 24V AC |
| Contactor Style | IEC |
| Depth | 5.59" , 6.89" |
| Embedded Surge Suppressor | Yes |
| Enclosure Nema Rating | No Enclosure |
| Frame Size | G |
| Frequency | 50/60 Hz |
| Full Load Amps-inductive | 115A |
| Full Load Amps-resistive | 200A |
| Full Load Current - Resistive | 200A |
| Height | 5 6/25" , 6.69" |
| Horsepower @ Single Phase - 240v Ac | 40 hp |
| Horsepower @ Three Phase (600 Vac) | 90 hp |
| Horsepower @ Three Phase - 208v Ac | 40 hp |
| Horsepower @ Three Phase - 480v Ac | 100 hp |
| Hp @ 1 Phase - 240v | 40 hp |
| Hp @ 3 Phase - 208v | 40 hp |
| Hp @ 3 Phase - 240v | 50 hp |
| Hp @ 3 Phase - 480v | 100 hp |
| Hp @ 3 Phase - 575v | 125 hp |
| Includes Auxiliary Contacts | No |
| Integrated Surge Suppression | Yes |
| Ip Rating | IP20 |
| Main Power Pole Contact Form | 4NO |
| Maximum Operating Temperature | 122°F |
| Maximum Voltage Rating | 690V AC |
| Mechanical Operating Durability | 10000000 |
| Minimum Operating Temperature | -13°F |
| Mounting Hole Dia. | 6/25" |
| Mounting Hole Distance | 6.14" |
| Mounting Hole Distance - Width | 2 19/25" |
| Mounting Style | Din Rail, Panel |
| Nema Enclosure Material | Not Applicable |
| Nominal Coil Voltage @ 60hz | 24V AC |
| Number Of Auxillary Contacts | 0 |
| Number Of Poles | 4 |
| Overall Depth | 6.89" |
| Overall Height | 6.69" |
| Overall Width | 5.24" |
| Phase | Three |
| Reversible | No |
| Reversing Capability | Non-reversing |
| Series | Xt Series Series |
| Terminal Connection Type | Screw Terminals |
| Width | 5 6/25" |
| Wire Termination Type | Screw |
Shipping Info:
| Ship weight (kg) | 2.88 |
| Ship height (cm) | 16.99 |
| Ship length (cm) | 17.5 |
| Ship width (cm) | 13.31 |
| Country of Origin | DE |
Product Variants
| Product | Model | Number Of Poles | Frame Size | Reversing Capability | Main Power Pole Contact Form | Auxiliary Contacts Included | Nominal Coil Voltage @ 60hz | Height | Includes Auxiliary Contacts | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
XTCE115G00A | 3 | G | Non-reversing | 3NO | None | 120V AC | 3 4/5" | No | €1,204.16 | |
|
XTCE115G00B | 3 | G | Non-reversing | 3NO | None | 240V AC | 6.693" | No | €1,204.16 | |
|
XTCE115G00T | 3 | G | Non-reversing | 3NO | None | 24V AC | 6.693" | No | €1,204.16 | |
|
XTCE115G00TD | 3 | G | Non-reversing | 3NO | None | 24V DC | 6.693" | No | €1,428.44 | |
|
XTCE115G00C | 3 | G | Non-reversing | 3NO | None | 480V AC | 170 mm | No | €1,110.61 | |
 |
XTCR115G11A | 3 | G | Reversing | 3NO | 1NO/1NC | 120V AC | 6" | Yes | €3,380.76 | |
 |
XTCF125G00A | 4 | G | Non-reversing | 4NO | None | 120V AC | 6.693" | No | €1,465.45 |
