EATON XTCE170G00T IEC Magnetic Contactor, Non-Reversing, 3 Poles, 170 A, 24 VAC Coil, G Frame Size
Item: BH8XXKModel: XTCE170G00TCross Ref: 4TZG2
7 In Stock
Ships within 2 days via
5.00% off
€1,988.70 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | IEC Magnetic Contactor |
| Auxiliary Contacts Included | None |
| Coil Voltage | 24V AC |
| Contactor Style | IEC |
| Depth | 6.26" , 7 6/25" |
| Electrical Operating Durability | 300 (AC-4 400V Ie), 800 (AC-1 400V Ie), 800 (AC-3 400V Ie) |
| Embedded Surge Suppressor | Yes |
| Enclosure Nema Rating | No Enclosure |
| Frame Size | G |
| Frequency | 50/60 Hz |
| Full Load Amps-inductive | 170A |
| Full Load Amps-resistive | 275A |
| Height | 12 4/5" , 3.54" |
| Hp @ 1 Ph-240v | 30 hp |
| Hp @ 1 Phase-120v | 10 hp |
| Hp @ 1 Phase-240v | 30 hp |
| Hp @ 3 Ph-480v | 125 hp |
| Hp @ 3 Phase-208v | 40 hp |
| Hp @ 3 Phase-240v | 60 hp |
| Hp @ 3 Phase-480v | 125 hp |
| Hp @ 3 Phase-575v | 125 hp |
| Hp @ 3 Phase-600v | 125 hp |
| Included Auxiliary Contacts | No |
| Integrated Surge Suppression | Yes |
| Ip Rating | IP20 |
| Main Power Pole Contact Form | 3NO |
| Max. Operating Temp. | 122°F |
| Max. Voltage | 690V AC |
| Mechanical Operating Durability | 10000000 |
| Min. Operating Temp. | -13°F |
| Mounting Hole Dia. | 0.27" |
| Mounting Hole Distance | 11.77" |
| Mounting Hole Distance Width | 6.97" |
| Mounting Style | DIN Rail, Panel |
| Nema Enclosure Material | Not Applicable |
| No. Of Auxillary Contacts | 0 |
| No. Of Poles | 3 |
| Nominal Coil Voltage @ 60hz | 24V AC |
| Overall Depth | 7.24" |
| Overall Height | 12 4/5" |
| Overall Width | 7.72" |
| Phase | 3 |
| Reversible | No |
| Reversing Capability | Non Reversing |
| Series | Xt Series Series |
| Terminal Connection Type | Screw Terminal |
| Width | 3.54" , 7 18/25" |
| Wire Termination Type | Screw |
Shipping Info:
| Ship weight (kg) | 2.34 |
| Ship height (cm) | 32.51 |
| Ship length (cm) | 18.39 |
| Ship width (cm) | 19.61 |
| Country of Origin | DE |
Product Variants
| Model | Frame Size | Reversing Capability | Main Power Pole Contact Form | Auxiliary Contacts Included | Nominal Coil Voltage @ 60hz | Height | Reversible | Depth | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| XTCE007B01A | B | Non Reversing | 3NO | 1NC | 120V AC | 2" | - | - | €250.30 | |
| XTCE007B01C | B | Non Reversing | 3NO | 1NC | 480V AC | 3 1/2" | - | - | €239.42 | |
| XTCE007B01E | B | Non Reversing | 3NO | 1NC | 208V AC | 3" | - | - | €239.42 | |
| XTCE007B01B | B | Non Reversing | 3NO | 1NC | 240V AC | 3.07" | - | - | €250.30 | |
| XTCE007B01T | B | Non Reversing | 3NO | 1NC | 24V AC | 1 1/2" | - | - | €250.30 | |
| XTCE007B01TD | B | Non Reversing | 3NO | 1NC | 24V DC | 3" | - | - | €334.78 | |
| XTCE007B10A | B | Non Reversing | 3NO | 1NO | 120V AC | 2.67" | - | - | €238.92 |
