EATON QCHW2080 Thermal-Magnetic Circuit Breaker, Type Qchw, 80 A, 22 Kaic, 2-Pole, 120/240 V, Fixed
Get it by Friday, Aug 21
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Circuit Breaker |
| Amps | 80A |
| Circuit Breaker Type | QCHW |
| Connection | Cable-in/cable-out |
| Height | 3" |
| Interrupt Rating | 22 kAIC |
| Length | 4" |
| No. Of Poles | 2 |
| Terminals | Fixed |
| Trip Type | Thermal-magnetic |
| Type | Industrial Circuit Breaker |
| Voltage Type | AC |
| Width | 2" |
Shipping Info:
| Ship weight (kg) | 0.23 |
| Ship height (cm) | 7.62 |
| Ship length (cm) | 10.16 |
| Ship width (cm) | 5.08 |
| Country of Origin | US |
Product Details:
- Eaton QCHW2080 Quicklag miniature ground fault circuit breaker for protection against electrical shocks and fire hazards in laundry, kitchen or wet areas
- QCHW breaker having QC frame design and 2 pole, 1 phase configuration for ground fault protection
- Features thermal magnetic trip with 5mA sensitivity for providing both long time and instantaneous trip functions for mild overloading and severe short circuiting, respectively
- Equipped with line & load side lug terminals for secure connection in limited space
- Feed-thru mounting for quick and easy installation
- UL listed and CSA certified
Product Variants
| Product | Model | Height | Amps | Type | No. Of Poles | Voltage | Circuit Breaker Type | Interrupt Rating | Trip Type | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
QC1050 | 4 4/5" | 50A | Industrial Circuit Breaker | 1 | - | QC | 10 kAIC | Thermal-magnetic | €30.67 | |
 |
QC1060 | 4 4/5" | 60A | Industrial Circuit Breaker | 1 | - | - | 10 kAIC | Thermal-magnetic | €30.67 | |
 |
QC2050 | 4 4/5" | 50A | Industrial Circuit Breaker | 2 | 120/240V | QC | 10 kAIC | Thermal-magnetic | €63.61 | |
 |
QC2060 | 4 4/5" | 60A | Industrial Circuit Breaker | 2 | - | QC | 10 kAIC | Thermal-magnetic | €67.21 | |
 |
QC2070 | 4.7" | 70A | Industrial Circuit Breaker | 2 | 120/240V | QC | 10 kAIC | Thermal-magnetic | €121.22 | |
 |
QC2080 | 4 4/5" | 80A | Industrial Circuit Breaker | 2 | 120/240V | QC | 10 kAIC | Thermal-magnetic | €149.84 | |
 |
QC2090 | 1.9" | 90A | Industrial Circuit Breaker | - | - | QC | 10 kAIC | Thermal-magnetic | €149.84 |
