EATON HMCPE070M2CBP08 Motor Circuit Protector, 70A, 3-Pole, 600 V, 250 Vdc, Frame J-K, 210-700A, Non-Aluminum
Get it by Tuesday, Feb 24
€2,939.35 /unit
Add To Cart
Request a Quote
Payment
Delivery
Product Specifications:
| Item | Motor Circuit Protector |
| Amperage Rating | 70A |
| Features | Bulk Pack 8 |
| Frame Size | Frame J-K |
| Height | 0.001" |
| Length | 6" |
| Magnetic Trip Range | 210-700A |
| Mfr. Series | Series G |
| Notes | Motor FLA Ranges Typical. The Corresponding Trip Setting Is at 13X The Minimum FLA Value Shown. For DC Applications, Trip Levels Are 40% Higher Than Values Shown. Includes Line And Load Steel Body Termianls For Cu Only Wire, 14 - 1/0. |
| Number Of Poles | 3 |
| Terminals | Non Aluminum |
| Type | Motor Circuit Protector |
| Voltage | 600V, 250V DC |
| Warranty | Eaton Selling Policy 25-000, One (1) Year From The Date Of Installation Of The Product Or Eighteen (18) Months From The Date Of Shipment Of The Product, Whichever Occurs First. |
| Width | 0.001" |
Shipping Info:
| Ship length (cm) | 15.24 |
| Country of Origin | US |
Product Variants
| Product | Model | Frame Size | Voltage | High Amp Trip Setting | Low Amp Trip Setting | Number Of Poles | Circuit Breaker Type | Ac Voltage Rating | Phase | Pkg. Qty. | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
HMCPE003A0C | Frame J-K | 480V | - | - | 3 | - | - | - | 1 | €1,123.01 | |
 |
HMCPE007C0C | Frame J-K | 480V | - | - | 3 | - | - | - | 1 | €1,123.01 | |
 |
HMCPE015E0C | - | 480V | 13A | 3.4A | 3 | Standard | 600V AC | Three | 1 | €1,123.01 | |
|
HMCPE030H1C | - | 480V | 26A | 3.9A | 3 | Standard | 600V AC | Three | 1 | €1,123.01 | |
|
HMCPE050K2C | - | 480V | 43.5A | 11.5A | 3 | Standard | 600V AC | Three | 1 | €1,123.01 | |
|
HMCPE070M2C | - | 480V | 60.9A | 16.1A | 3 | Standard | 600V AC | Three | 1 | €1,421.35 | |
|
HMCPE100R3C | - | 480V | 84.5A | 23A | 3 | Standard | 600V AC | Three | 1 | €1,421.35 |
