EATON BRP115AF Circuit Breaker, 15 A, 120 VAC, Single Phase, 10kA at 120 VAC, Type BR Loadcenters, 1 Pole
Item: CE6GFQModel: BRP115AFCross Ref: 60JL44
7 In Stock
Ships within 2 days via
10.00% off
€63.91 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Circuit Breaker |
| Ac Voltage Rating | 120V AC |
| Amperage Rating | 15A |
| Circuit Breaker Actuator | Toggle |
| Circuit Breaker Mounting Style | Plug In |
| Circuit Breaker Type | Combination Arc Fault Circuit Interrupter |
| Compatible Panelboard/load Center Series | BR Series |
| Connection | Plug-On |
| Dc Voltage Rating | Not Rated |
| Depth | 1.1" |
| Features | Ul Only |
| For Use With | Type BR Loadcenters |
| Height | 1.1" |
| Interrupt Rating | 10 kAIC |
| Length | 2 14/25" |
| Main Circuit Breaker | BR |
| Max. Air Rating | 10 kA At 120V AC |
| Max. Wire Size | 8 AWG |
| Min. Wire Size | 14 AWG |
| Neutral | Plug-On Neutral |
| Number Of Poles | 1 |
| Phase | Single |
| Type | AFCI Combination Circuit Breaker |
| Voltage | 120V AC |
| Voltage Type | AC |
| Width | 1" |
| Wire Size | #14 AWG to 8 AWG |
Shipping Info:
| Ship weight (kg) | 0.17 |
| Ship height (cm) | 2.79 |
| Ship length (cm) | 6.5 |
| Ship width (cm) | 2.54 |
| Country of Origin | US |
Product Details:
- EATON BRP115AF combination arc fault (AFCI) circuit interrupter designed to detect electrical arcs and prevent electrical fires
- Ideal for use in HVAC systems and laundry & kitchen areas where risk of electrical fires and shocks is high
- Single pole, single phase design with thermal-magnetic trip providing both long time and instantaneous current tripping
- Features integral LED to determine trip cause and provide quick troubleshoot & maintenance
- Accommodates copper and aluminium wires of sizes 14 to 8 AWG
- Miniature BR frame circuit breaker for better loadcentre area management & gutter space with clutter free pigtail
- UL listed & RoHS compliant
Product Variants
| Product | Model | Number Of Poles | Voltage | Ac Voltage Rating | Phase | Amps | Min. Wire Size | Dc Voltage Rating | Circuit Breaker Actuator | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
BRL220AF | 2 | 120/240V | - | - | - | - | - | - | - | RFQ
|
 |
BRN115AF | 1 | 120V AC | 120V AC | Single | - | 14 AWG | Not Rated | Toggle | €80.26 | |
|
BRN120AF | 1 | 120V AC | 120V AC | Single | - | 14 AWG | Not Rated | Toggle | €80.26 | |
|
BRP120AF | 1 | 120V AC | 120V AC | Single | 20A | 14 AWG | Not Rated | Toggle | €71.01 | |
 |
BRAF120 | 1 | - | - | - | - | - | - | - | €485.26 | |
 |
BRCAF115CS | 1 | 120V AC | - | - | - | - | - | - | €514.62 | |
 |
BRCAF120CS | 1 | 120V AC | - | - | - | - | - | - | €489.33 |
