DYNAQUIP CONTROLS PVA64AMDA052A Automated Ball Valve, 3 Pcs, Full Port, Brass, 3.2 Inch Overall Length
Item: AD2RNYModel: PVA64AMDA052ACross Ref: 3TPH4
7 In Stock
Ships within 2 days via
13.00% off
€804.29 /unit
Add To Cart
Request a Quote
Payment
Product Specifications:
| Item | Ball Valve |
| 3-a Certified | Not Rated |
| Actuation | Pneumatically Actuated |
| Actuator Air Pressure Range | 80 psi to 300 psi |
| Actuator Features | Position Indicator |
| Actuator Operation | Air To Air |
| Actuator Series | HP |
| Actuator Type | Double Acting |
| Ambient Temp. | -4°F to +176°F |
| Ansi Flange Class | Not Applicable |
| Average Surface Roughness (ra) | Not Applicable |
| Ball Material | Stainless Steel |
| Ball Port Style | Full Port |
| Ball Valve Product Group | Actuated |
| Body Material | Brass |
| Body Style | Inline |
| Coefficient Of Volume(cv) | 35 |
| Connection Gender | Threaded |
| Connection Gender Side 2 | Female |
| Connection Gender-side 1 | Female |
| Connection Size-side 1 | 3/4" |
| Connection Size-side 2 | 3/4" |
| Connection Type | FNPT x FNPT |
| Connection Type-side 1 | NPT |
| Connection Type-side 2 | NPT |
| Cwp | 600 psi |
| Fail Safe Position | Fail Last |
| For Media | Air, Oil, Water |
| General Connection Type | Female NPT |
| Grade | Grade 316 |
| Included Mounting | Iso 5211 Actuator Mounting Pad |
| Included Pilot Solenoid | 115V AC Pilot Solenoid |
| Ip Rating | IP65 |
| Max. Actuator Air Pressure | 300 psi |
| Max. Actuator Ambient Temp. | 176°F |
| Max. Differential Pressure | 300 psi |
| Max. Inlet Pressure | 300 psi |
| Max. Media Temp. | 400°F |
| Max. Operating Temp. | 400°F |
| Max. Pressure | 600 psi |
| Max. Pressure (cwp) | 600 psi |
| Max. Pressure-combustible Gas | Not Rated |
| Max. Pressure-steam | 125 psi |
| Media Temp. | -20°F to +400°F |
| Min. Actuator Air Pressure | 80 psi |
| Min. Actuator Ambient Temp. | -4°F |
| Min. Media Temp. | -20°F |
| Mount | Direct |
| Nema Enclosure Rating | NEMA 4, NEMA 4X |
| No. Of Pieces | 3 |
| Nominal Valve Size | 3/4" |
| Operation | Double Acting |
| Overall Length | 3.2" |
| Pilot Solenoid Voltage | 115V AC |
| Pipe Schedule Compatibility | Not Applicable |
| Pipe Size | 3/4" |
| Port | Full |
| Porting Style | Full Port |
| Required Pressure | 80 psi |
| Seal Material | FKM, PTFE |
| Seal Type | Viton |
| Seat Material | PTFE |
| Stem Material | Stainless Steel |
| Temp. | +14°F to +140°F |
| Type | Full Port |
| Vacuum Service Rating | 29 in. hg |
| Valve Body Style | Straight |
| Valve Construction | Three-Piece |
| Valve Deactivated State | normally Open (NO), normally Closed (NC) |
| Valve Series | Pva |
| Valve Ways | 2-Way |
| Vented Ball Valve | Non Vented |
Shipping Info:
| Ship weight (kg) | 2.8 |
| Ship height (cm) | 10.67 |
| Ship length (cm) | 20.83 |
| Ship width (cm) | 15.49 |
| HS code | 8481809040 |
| Country of Origin | CN |
Product Variants
| Model | Nominal Valve Size | Connection Size-side 2 | Connection Size-side 1 | Operation | Actuator Operation | Actuator Type | Fail Safe Position | Valve Deactivated State | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| PVA63AMDA052A | 1/2" | 1/2" | 1/2" | Double Acting | Air To Air | Double Acting | Fail Last | normally Open (NO), normally Closed (NC) | €897.69 | |
| PVA65AMDA052A | 1" | 1" | 1" | Double Acting | Air To Air | Double Acting | Fail Last | normally Open (NO), normally Closed (NC) | €1,028.36 | |
| PVA68AMDA063A | 2" | 2" | 2" | Double Acting | Air To Air | Double Acting | Fail Last | normally Open (NO), normally Closed (NC) | €1,380.53 | |
| PVA63AMSR05210A | 1/2" | 1/2" | 1/2" | Spring Return Fail Closed | Air To Spring | Single Acting Spring Return | Fail Closed | normally Closed (NC) | €1,104.04 | |
| PVA64AMSR05212A | 3/4" | 3/4" | 3/4" | Spring Return | Air To Spring | Single Acting Spring Return | Fail Closed | normally Closed (NC) | €1,143.12 | |
| PVA65AMSR06312A | 1" | 1" | 1" | Spring Return | Air To Spring | Single Acting Spring Return | Fail Closed | normally Closed (NC) | €1,140.72 | |
| PVA67AMSR07512A | 1 1/2" | 1 1/2" | 1 1/2" | Spring Return | Air To Spring | Single Acting Spring Return | Fail Closed | normally Closed (NC) | €1,329.53 |
